FARGO Electronics Inc.
HDP700 Series Card Printer
A-1
Section
7
7.1 Entering the LCD Menu and Selecting an Option
Ready
HDP7XX (v X.X.X)
MENU
Figure 7-1
The MENU option is above the center softkey button. See Figure 7-3 and Figure 7-1. This allows you
to access several test, setup, and reporting functions. The tree structure on page 7- 4 shows the
available menu options. A description of each option and its function is included on the pages following
the on-line menu.
Press the MENU button. The SELECT FUNCTION screen appears. See Figure 7-2.
SELECT FUNCTION
SELECT
HELP
EXIT
[Print Test Image]
Setup Printer
Figure 7-2
Use the scroll buttons to move up or down through the menu options. See Figure 7-3. Brackets appear
on either side of the active menu option. Press the button below SELECT to choose an option. There
are five categories to choose from: PRINT TEST IMAGE, SETUP PRINTER, SHOW ERROR
COUNT
, SHOW CARD COUNT, and SYSTEM UPGRADE.
Figure 7-3
