MSD-804FD Users Guide (Command Guide)
71
@SVF Set PC resolution (EDID)
Command
format @SVF, ch_1, resolution_1 (, ch_2, resolution_2･･･)
Return value
format @SVF, ch_1, resolution_1 (, ch_2, resolution_2･･･)
Parameter ch_1-9 : Input channel
0 = All inputs, 1 = IN1 to 9 = IN9
resolution_1-9 : Resolution
0 = SVGA(800x600), 1 = XGA(1024x768), 2 = 720p(1280x720),
3 = WXGA(1280x768), 4 = WXGA(1280x800), 5 = Quad-VGA(1280x960),
6 = SXGA(1280x1024), 7 = WXGA(1360x768), 8 = WXGA(1366x768),
9 = SXGA+(1400x1050), 10 = WXGA+(1440x900), 11 = WXGA++(1600x900),
12 = UXGA(1600x1200), 13 = WSXGA+(1680x1050), 14 = 1080i(1920x1080),
15 = 1080p(1920x1080), 16 = WUXGA(1920x1200), 17 = QWXGA(2048x1152)
[Default]: If ch_1-9 is 1 (IN1) to 5 (IN5): 1080p (1920x1080),
ch_1-9 is 6 (IN6) to 9 (IN9): UXGA (1600x1200)
Example Send
Receive
@SVF,0,12
@SVF,0,12 Set EDIDs of all input channel to 1600x1200 (UXGA).
Terminated normally.
Related info. 8.9.2 PC resolutions
@GVF Get PC resolution (EDID)
Command
format @GVF
Return value
format @GVF, in_1, in_2, in_3, in_4, in_5, in_6, in_7, in_8, in_9
Parameter in_1 , in_2, in_3, in_4, in_5, in_6, in_7, in_8, in_9 : Resolution of each input channel
0 = SVGA(800x600), 1 = XGA(1024x768), 2 = 720p(1280x720),
3 = WXGA(1280x768), 4 = WXGA(1280x800), 5 = Quad-VGA(1280x960),
6 = SXGA(1280x1024), 7 = WXGA(1360x768), 8 = WXGA(1366x768),
9 = SXGA+(1400x1050), 10 = WXGA+(1440x900), 11 = WXGA++(1600x900),
12 = UXGA(1600x1200), 13 = WSXGA+(1680x1050), 14 = 1080i(1920x1080),
15 = 1080p(1920x1080), 16 = WUXGA(1920x1200), 17 = QWXGA(2048x1152)
[Default]: If ch_1-9 is 1 (IN1) to 5 (IN5): 1080p (1920x1080),
ch_1-9 is 6 (IN6) to 9 (IN9): UXGA (1600x1200)
Example Send
Receive
@GVF
@GVF,6,6,9,6,6,6,6,6,6
Get PC resolution.
IN3: 1400x1050; other inputs: 280x1024
Related info. 8.9.2 PC resolutions
