The RAX System Design Table below is to assist in determining the mix and quantity of RAX system components.
IV. RAX System Equipment Requirements
RAX SYSTEM DESIGN TABLE
SYSTEM COMPONENTS
QUANTITY OF COMPONENTS
RAX-8 RAX-16 RAX-24
RAX-8 Central Exchange Unit for up to 8 stations (with 2 XC-063) 1
RAX-16 Central Exchange Unit for up to 16 stations(with 4XC-063) 1
RAX-24 Central Exchange Unit for up to 24 stations (with 6XC-063) 1
STATION MODEL
RA-A
RA-D
RA-B
RA-C
Open voice master station, with handset
communication capability
Speaker-phone type master station
Open voice master station, flush-mount
Open voice sub station, flush-mount
max. 8 max. 16 max. 24
OPTIONAL ACCESSORIES
PG-B
PG-10B
PG-A
PG-10A
Standard amplifier (available except in N. America)
l o w
UL/CSA approved amplifier
(available only in N. America)
l o w
Up to 4 separate zones either for paging or
remote control
Each zone requires 1 PG-A or PG-B amplifier,
1 MC-A adaptor and a required number of
speakers. (Does not reduce station capacity)
OR
When using one RC-A adaptor, as well as a
required number of speakers for each paging zone,
system can have only to use 1 each PG-A (or
PG-B) amplifier, MC-A adaptor, PB-YKX
talkback adaptor. (Does not reduce station
capacity)
MC-A Paging adaptor
SP-3NA
NBZ-M
N-EA
Standard 3 watt ceiling speaker
Square frame for SP-3NA.
Round frame for SP-3NA.
RC-A Zone paging adaptor
PB-YKX Talkback adaptor 1 for each paging zone where talkback is required.
RC-B
Remote control adaptor to be used in conjunction with
external devices such as lights, background music, etc.
1 for each zone where external device is located.
Note; System may include total of four MC-A and/or RC-B.
