4. Open voice sub station: RA-C (Flush-mount)
IX. RAX System Specifications (continued)
Power source
Current consumption
Communication
Calling
Key pad
Station selection
Mounting
Front panel
DC 24V supplied by Central Exchange Unit.
DC 10mA (maximum)
Loudspeaking voice-actuated
Pre-tone and call LED illumination
2-touch key buttons
1 button (I 1)
Flush-mount
Stainless steel
5. Paging adaptor: MC-A
* Power source
* Current consumption
DC 24V supplied by Central Exchange Unit.%
Maximum 20mA in standby mode
Maximum 50mA (max.) in paging mode
6. Talkback adaptor: PB-YKX
* Power source
* Current consumtion
DC 24V supplied by Central Exchange Unit.
Maximum 2mA in standby mode
Maximum 40mA (max.) in talkback paging mode
7. Remote control adaptor: RC-A, RC-B
Power source
Current consumption
Permitted contact capacity
DC 24V supplied by RAX Central Exchange Unit
Maximum 40mA (max.)
Maximum AC 120V, 3A.
Maximum DC 24V, 3A.
Minimum applicable load: DC 5V, 100mA.
PERMITTED LINE DISTANCE
0.5 mm 0.65 mm 0.8 mm 24 AWG 22 AWG 20 AWG
1
RAX CEU - RA-A, RA-C
RA-B
RA-D
350 m 600 m 900 m 1,200' 2,000' 3,000'
RAX CEU - MC-A
RC-A
RC-B
90 m 150 m 230 m 300' 500' 800'
RAX-CEU - PB-YKX 530 m 890 m 1,350 m 1,800' 3,000' 4,500'
-24-
