MAX31782 User’s Guide
Revision 0; 8/11
*Set by hardware only.
7.2.2I 2 CSlaveStatusRegister(I2CST�S)
Address: M2[01h]
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name I2CBUS I2CBUSY — — I2CSPI I2CSCL I2CROI I2CGCI I2CNACKI — I2CAMI I2CTOI I2CSTRI I2CRXI I2CTXI I2CSRI
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Access r* r* r r rw r* rw rw rw* r rw rw rw* rw* rw rw
BIT NAME DESCRIPTION
15 I2CBUS
I 2 C Slave Bus Busy . This bit is set to 1 when a START/repeated START condition is detected and cleared
to 0 when the STOP condition is detected . This bit is reset to 0 on all forms of reset or when I2CEN = 0 .
This bit is controlled by hardware and is read only .
14 I2CBUSY
I 2 C Slave Busy . This bit is used to indicate the current status of the I 2 C module . The I2CBUSY is set to 1
when the I 2 C controller is actively participating in a transaction . This bit is controlled by hardware and is
read only .
13:12 — Reserved . The user should not write to these bits .
11 I2CSPI
I 2 C Slave STOP Interrupt Flag . This bit is set to 1 when a STOP condition is detected . This bit must be
cleared to 0 by software once set . Setting this bit to 1 by software causes an interrupt if enabled .
10 I2CSCL
I 2 C Slave SCL Status . This bit reflects the logic state of SCL signal . This bit is set to 1 when SCL is at a
logic-high (1), and cleared to 0 when SCL is at a logic-low (0) . This bit is controlled by hardware and is
read-only .
9 I2CROI
I 2 C Slave Receiver Overrun Flag . This bit indicates a receive overrun when set to 1 . This bit is set to 1 if
the receiver has received 2 bytes since the last CPU read of I2CBUF_S . This bit can only be cleared to 0
by software reading the I2CBUF_S . Setting this bit to 1 by software causes an interrupt if enabled .
8 I2CGCI
I 2 C Slave General Call Interrupt Flag . This bit is set to 1 when the general call is enabled (I2CGCEN = 1)
and the general call address (00h) is received . This bit must be cleared to 0 by software once set . Setting
this bit to 1 by software causes an interrupt if enabled .
7 I2CNACKI
I 2 C Slave NACK Interrupt Flag . This bit is set by hardware to either a 1 if a NACK was received from
the host or a 0 if an ACK was received from the host . The setting of this bit to a 1 causes an interrupt if
enabled . This bit can be cleared to 0 by software once set .
6 — Reserved . The user should not write to these bits .
5 I2CAMI
I 2 C Slave Address Match Interrupt Flag . This bit is set to 1 when the I 2 C controller receives an address
that matches the contents of the slave address register (I2CSLA_S) . This bit must be cleared to 0 by soft-
ware once set . Setting this bit to 1 by software causes an interrupt if enabled .
4 I2CTOI
I 2 C Slave Timeout Interrupt Flag . This bit is set to 1 if SMBus timeout is enabled and SCL is low longer than
30ms . This bit must be cleared to 0 by software once set . Setting this to 1 causes an interrupt if enabled .
3 I2CSTRI
I 2 C Slave Clock Stretch Interrupt Flag . This bit indicates that the I 2 C slave controller is operating with
clock stretching enabled and is currently holding the SCL clock signal low . The I 2 C controller releases
SCL after this bit has been cleared to 0 . This bit must be cleared to 0 by software once set . This bit is set
by hardware only .
2 I2CRXI
I 2 C Slave Receive Ready Interrupt Flag . This bit indicates that a data byte has been received in the I 2 C
buffer . This bit must be cleared by software once set . This bit is set by hardware only .
1 I2CTXI
I 2 C Slave Transmit Complete Interrupt Flag . This bit indicates that an address or a data byte has been
successfully shifted out and the I 2 C controller has received an acknowledgment from the receiver (NACK
or ACK) . This bit must be cleared by software once set . Setting this bit to 1 by software causes an inter-
rupt if enabled .
0 I2CSRI
I 2 C Slave START Interrupt Flag . This bit is set to 1 when a START condition (or restart) is detected . This bit
must be cleared to 0 by software once set . Setting this bit to 1 by software causes an interrupt if enabled .
