Model 9000/9100/9500
31
9500 Brine Valve Systems (1600 and 1700 Series)
Figure 26
Figure 27
Item Quantity Part Number Description
1 1 16922 bracket, brine valve 1600 Series Brine System
2 2 15137 screw, brine valve bracket
3 1 60037-610 brine valve assembly, 0.25 gpm
60020-620 brine valve assembly, 0.50 gpm
60020-630 brine valve assembly, 1.00 gpm
60020-690 brine valve assembly, blank
60037HW brine valve assembly, hot water
3A 1 60020-25 brine line flow control assembly, 0.25 gpm
60020-50 brine line flow control assembly, 0.50 gpm
60020-100 brine line flow control assembly, 1.00 gpm
4 1 tube, brine valve
5 1 adapter kit
6 1 16922 bracket, brine valve 1700 Series Brine System
7 2 15137 screw, brine valve bracket
8 2 15414 nut, tube
9 1 16959 tube, brine valve
10 1 60039-00 brine valve assembly, blank
60039-10 brine valve assembly, 1.0 gpm
60039-12 brine valve assembly, 1.2 gpm
60039-15 brine valve assembly, 1.5 gpm
60039-20 brine valve assembly, 2.0 gpm
60039-24 brine valve assembly, 2.4 gpm
60039-30 brine valve assembly, 3.0 gpm
60039-35 brine valve assembly, 3.5 gpm
60039-40 brine valve assembly, 4.0 gpm
