Model 9000/9100/9500
29
9100 Control Valve Assembly
Item Quantity Part Number Description
1 1 40688 valve body assembly
2 4 15137 screw, hex washer #10-24 x 3/8”
3 1 14906 end plate
4 1 14928 end plug
5 1 19054 O-ring, 124
6 1 18303 O-ring, 336
7 1 40538 retainer, 32mm
8 1 60400 piston top assembly
9 1 60125 seal and spacer kit, top
1 60125-20 seal and spacer kit, top (559PE)
10 1 60421 seal and spacer kit, bottom
1 60421-20 seal and spacer kit, bottom (559PE)
11 1 60401 piston assembly, bottom
12 1 60385-XXXX injector assembly
(see following chart for dash numbers)
injector number DLFC number BLFC number
red #0 00 Blank 0 Blank 0
white #1 01 1.2 1 0.25 1
blue #2 02 1.5 2 0.50 2
yellow #3 03 2.0 3 1.00 3
green #4 04 2.4 4
3.0 5
3.5
6
4.0 7
5.0
8
7.0 9
12A 1 60022-12 brine line flow control assembly, 0.125 gpm
60022-25 brine line flow control assembly, 0.250 gpm
60022-50 brine line flow control assembly, 0.500 gpm
60022-100 brine line flow control assembly, 1.00 gpm
12B 1 60350 brine valve assembly
13 1 61419 distributor adapter kit, 1.05"
Not Shown
14
12763 seal and space stuffer tool
15 13061 spacer puller tool
16 13759 DLFC retainer tool
