5
ARI* CAPACITIES
LEGEND
*Air-Conditioning & Refrigeration Institute.
†Applies only to units with capacity of 65,000 Btuh or less.
**The IPLV is not applicable to single-compressor units.
NOTES:
1. Rated in accordance with ARI Standard 210/240 (size 036-120 units) or 360
(size 150 units) and 270 (size 036-150 units).
2. Ratings are net values, reflecting the effects of circulating fan heat. Ratings are
based on:
Cooling Standard: 80 F db, 67 wb indoor entering-air temperature and 95 F
db outdoor entering-air temperature.
IPLV Standard: 80 F db, 67 F wb indoor entering-air temperature and 80 F
db outdoor entering-air temperature.
HEATING CAPACITIES AND EFFICIENCIES
LEGEND
AFUE — Annual Fuel Utilization Efficiency
*California rated three-phase models.
†Three-phase standard models have heating input values as shown. Single-phase standard models
have one-stage heating with heating input values as follows:
581BJV036-060072, 72,000 Btuh
581BJV036-060115, 115,000 Btuh
581BJV048-060150, 150,000 Btuh
**California SCAQMD compliant Low NOx models have combustion products that are controlled to
40 nanograms per joule or less.
UNIT
581B NOMINAL
TONS
STANDARD
CFM
COOLING
(Btuh)
TOTAL
kW
SEER† EER
SOUND RATING
(dB)
IPLV**
036 3 1200 36,000 3.21 13.00 11.20 76 —
048 4 1450 47,000 4.25 13.00 11.05 76 —
060 5 1750 60,000 5.55 13.00 11.00 80 —
072 6 2100 74,000 6.70 — 11.00 80 —
090 7 1 /
2
3000 90,000 8.18 — 11.00 82 11.6
102 8 1 /
2
3000 102,000 9.44 — 10.80 82 10.9
120 10 3200 120,000 10.91 — 11.00 84 9.7
150 12 1 /
2
4300 140,000 14.04 — 9.50 86 9.8
dB — Decibels
EER — Energy Efficiency Ratio
IPLV — Integrated Part-Load Value
SEER — Seasonal Energy Efficiency Ratio
SIZE
581B
HEATING INPUT (Btuh)
Stage 2/Stage 1
OUTPUT CAPACITY
(Btuh)
TEMPERATURE
RISE
AFUE
(%)
STEADY-STAGE
EFFICIENCY (%)
036071* —/ 72,000 —/ 59,040 15-45 82 82
036072† 72,000/ 50,000 59,040/ 41,000 15-45 82 82
036114* —/115,000 —/ 92,000 55-85 80 80
036115† 115,000/ 82,000 92,000/ 65,600 55-85 80 82
036060N** —/ 60,000 —/ 50,000 20-50 81 81
036090N** — 90,000 —/ 74,000 30-60 81 81
048071* —/ 72,000 —/ 59,040 15-45 82 82
048072† 72,000/ 50,000 59,040/ 41,000 15-45 82 82
048114* —/115,000 —/ 92,000 35-65 81 81
048115† 115,000/ 82,000 93,150/ 66,420 35-65 81 81
048149* —/150,000 —/120,000 50-80 80 80
048150† 150,000/120,000 120,000/ 96,000 50-80 80 80
048060N** —/ 60,000 —/ 50,000 20-50 81 81
048090N** —/ 90,000 —/ 74,000 30-60 81 81
048120N** —/120,000 —/101,000 40-70 82 82
060071* —/ 72,000 —/ 59,040 15-45 82 82
060072† 72,000/ 50,000 59,040/ 41,000 15-45 82 82
060114* —/115,000 —/ 93,150 35-65 81 81
060115† 115,000/82,000 93,150/ 66,420 35-65 81 81
060149* —/150,000 —/120,000 50-80 80 80
060150† 150,000/120,000 120,000/ 96,000 50-80 80 80
060060N** —/ 60,000 —/ 50,000 20-50 81 81
060090N** —/ 90,000 —/ 74,000 30-60 81 81
060120N** —/120,000 —/101,000 40-70 82 82
072072 72,000/ 50,000 59,040/ 41,000 15-45 82 82
072115 115,000/ 82,000 93,150/ 66,420 35-65 81 81
072150 150,000/120,000 120,000/ 96,000 50-80 80 80
090125 125,000/ 90,000 102,500/ 72,900 20-50 82 82
090180 180,000/120,000 147,600/ 98,400 35-65 82 82
090224 224,000/180,000 183,700/147,600 45-75 82 82
102125 125,000/ 90,000 102,500/ 72,900 20-50 82 82
102180 180,000/120,000 147,600/ 98,400 35-65 82 82
102224 224,000/180,000 183,700/147,600 45-75 82 82
120180 180,000/120,000 147,600/ 98,400 35-65 82 82
120224 224,000/180,000 183,700/147,600 45-75 82 82
120250 250,000/200,000 200,000/160,000 40-70 80 80
150224 224,000/180,000 183,700/147,600 45-75 82 82
150250 250,000/200,000 200,000/160,000 40-70 80 80
Sizes 036-120 Only Size 150 Only
