ACCESSORY DIMENSIONS — 581B036-072
UNIT
SIZE
581B
“A”
ROOF CURB
ACCESSORY
036-072
1
′-2″ [356] CRRFCURB001A00
2
′-0″ [610] CRRFCURB002A00
NOTES:
1. Roof curb accessory is shipped disassembled.
2. Insulated panels.
3. Dimensions in [
] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest on curb).
6. Service clearance 4 ft on each side.
7.
Direction of airflow.
8. Connector packages CRBTMPWR001A00 and 002A00 are for thru-the-curb connec-
tions. Packages CRBTMP003A00 and 004A00 are for thru-the-bottom connections.
UNIT SIZE
581B
B
C
D ALT
DRAIN
HOLE
“E”
GAS
“F”
POWER
“G”
CONTROL
CONNECTOR
PKG. ACCY.
036-072
1
′-9
11
/
16
″
[551]
1
′-4″
[406]
1
3
/
4
″
[44.5]
3
/
4
″
[19] NPT
3
/
4
″ [19] NPT
1
/
2
″
[12.7] NPT
CRBTMPWR001A00
1
1
/
4
″ [31.7]
CRBTMPWR002A00
1
/
2
″
[12.7] NPT
3
/
4
″ [19] NPT
1
/
2
″
[12.7] NPT
CRBTMPWR003A00
3
/
4
″
[19] NPT
1
1
/
4
″ [31.7]
CRBTMPWR004A00
