36
PERFORMANCE DATA (cont)
FAN PERFORMANCE — HORIZONTAL DISCHARGE UNITS (cont)
LEGEND
NOTES:
1. Boldface indicates field-supplied drive required. (See Note 3.)
2. indicates field-supplied motor and drive required.
3. Motor drive range is 1120 to 1585 rpm for standard motors; 1300 to 1685 rpm
for high-static motors. All other rpms require a field-supplied drive.
4. Values include losses for filters, unit casing, and wet coils. See page 40 for
accessory/FIOP static pressure information.
5. Maximum continuous bhp is 2.4 for standard motors; 2.9 for high-static
motors. Extensive motor and electrical testing on these units ensures that the
full range of the motor can be utilized with confidence. Using your fan motors
up to the ratings shown will not result in nuisance tripping or premature motor
failure. Unit warranty will not be affected. See Evaporator-Fan Motor Data
tables on pages 41 and 42 for additional information.
6. Use of a field-supplied motor may affect wire sizing. Contact your Bryant rep-
resentative to verify.
7. Interpolation is permissible. Do not extrapolate.
581B072 (6 TONS) — STANDARD MOTOR
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.1 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1800 885 0.63 942 0.73 1047 0.90 1139 1.05 1193 1.14 1276 1.30 1341 1.40 1413 1.55 1474 1.58
1900 928 0.73 982 0.83 1084 1.02 1160 1.11 1223 1.24 1301 1.38 1374 1.53 1437 1.62 1490 1.67
2000 971 0.84 1022 0.94 1121 1.12 1188 1.22 1254 1.36 1329 1.44 1396 1.66 1460 1.68 1509 1.77
2100 1015 0.97 1063 1.10 1140 1.18 1196 1.27 1272 1.45 1354 1.58 1413 1.75 1475 1.73 1529 1.92
2200 1060 1.10 1104 1.20 1159 1.23 1229 1.41 1306 1.53 1363 1.70 1434 1.81 1487 1.85 1554 2.07
2300 1104 1.25 1130 1.27 1196 1.37 1264 1.56 1340 1.66 1397 1.86 1459 1.88 1520 2.07 1576 2.24
2400 1138 1.30 1174 1.37 1245 1.57 1305 1.63 1373 1.84 1440 1.95 1502 2.06 1552 2.24 1604 2.42
2500 1183 1.43 1201 1.50 1284 1.65 1338 1.75 1402 1.99 1469 2.04 1524 2.24 1585 2.42 1638 2.60
2600 1210 1.58 1243 1.67 1312 1.76 1366 1.96 1435 2.10 1494 2.19 1552 2.40 1616 2.63 1671 2.80
2700 1254 1.76 1285 1.80 1354 1.95 1403 2.14 1474 2.21 1536 2.46 1584 2.61 1646 2.83 1706 2.97
2800 1274 1.82 1304 1.85 1374 2.12 1459 2.25 1514 2.42 1570 2.66 1624 2.85 1677 2.99 — —
2900 1318 1.95 1345 2.05 1412 2.32 1496 2.45 1529 2.61 1603 2.87 1671 3.03 — — — —
3000 1362 2.20 1378 2.30 1451 2.40 1534 2.66 1560 2.81 1611 3.01 — — — — — —
581B072 (6 TONS) — HIGH-STATIC MOTOR
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1800 942 0.73 1047 0.90 1139 1.05 1193 1.14 1276 1.30 1341 1.40 1413 1.55 1474 1.58 1522 1.74 1566 1.89
1900 982 0.83 1084 1.02 1160 1.11 1223 1.24 1301 1.38 1374 1.53 1437 1.62 1490 1.67 1538 1.84 1583 2.00
2000 1022 0.94 1121 1.12 1188 1.22 1264 1.36 1329 1.44 1396 1.66 1460 1.68 1509 1.77 1558 1.95 1603 2.12
2100 1063 1.10 1140 1.18 1196 1.27 1272 1.45 1354 1.58 1413 1.75 1475 1.73 1529 1.92 1578 2.11 1624 2.30
2200 1104 1.20 1159 1.23 1229 1.41 1306 1.53 1363 1.70 1434 1.81 1487 1.85 1554 2.07 1604 2.28 1651 2.48
2300 1130 1.27 1196 1.37 1264 1.56 1340 1.66 1397 1.86 1459 1.88 1520 2.07 1576 2.24 1627 2.46 1674 2.68
2400 1174 1.37 1245 1.57 1305 1.63 1373 1.84 1440 1.95 1502 2.06 1552 2.24 1604 2.42 1656 2.66 1704 2.90
2500 1201 1.50 1284 1.65 1338 1.75 1402 1.99 1469 2.04 1524 2.24 1585 2.42 1638 2.60 1691 2.86 1740 3.12
2600 1246 1.67 1312 1.76 1366 1.96 1435 2.10 1494 2.19 1552 2.40 1616 2.63 1671 2.80 1726 3.09 1775 3.35
2700 1285 1.80 1354 1.95 1403 2.14 1474 2.21 1536 2.46 1584 2.61 1646 2.83 1706 2.97 1761 3.27 — —
2800 1304 1.85 1374 2.12 1459 2.25 1514 2.42 1570 2.66 1624 2.85 1677 2.99 1739 3.33 1795 3.67 — —
2900 1345 2.05 1412 2.32 1496 2.54 1529 2.61 1603 2.87 1671 3.03 1742 3.43 — — — — — —
3000 1378 2.30 1451 2.40 1534 2.66 1560 2.81 1611 3.01 1692 3.49 1764 3.95 — — — — — —
Bhp — Brake Horsepower Input to Fan
FIOP — Factory-Installed Option
