29
PERFORMANCE DATA (cont)
FAN PERFORMANCE — VERTICAL DISCHARGE UNITS (cont)
LEGEND
NOTES:
1. Boldface indicates field-supplied drive required. (See Note 3.)
2. indicates field-supplied motor and drive required.
3. Motor drive range is 1120 to 1585 rpm for standard motors, 1300 to
1685 rpm for high-static motors. All other rpms require a field-supplied drive.
4. Values include losses for filters, unit casing, and wet coils. See page 40 for
accessory/FIOP static pressure information.
5. Maximum continuous bhp is 2.40 for standard motors, 2.90 for high-static
motors. Extensive motor and electrical testing on these units ensures that
the full range of the motor can be utilized with confidence. Using your fan
motors up to the ratings shown will not result in nuisance tripping or prema-
ture motor failure. Unit warranty will not be affected. See Evaporator-Fan
Motor Data tables on pages 41 and 42 for additional information.
6. Use of a field-supplied motor may affect wire sizing. Contact your Bryant
representative to verify.
7. Interpolation is permissible. Do not extrapolate.
581B072 (6 TONS) — STANDARD MOTOR
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.1 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1800 942 0.70 978 0.66 1063 0.82 1147 0.97 1248 1.20 1322 1.33 1395 1.46 1475 1.56 1542 1.71
1900 982 0.80 1023 0.78 1097 0.91 1175 1.11 1266 1.29 1356 1.47 1430 1.58 1504 1.69 1556 1.82
2000 1022 0.91 1068 0.90 1132 1.01 1218 1.23 1303 1.41 1397 1.52 1459 1.67 1532 1.82 1588 1.97
2100 1063 0.99 1115 1.00 1180 1.17 1261 1.35 1340 1.53 1428 1.66 1489 1.80 1567 1.99 1626 2.16
2200 1104 1.13 1159 1.15 1214 1.28 1310 1.52 1375 1.63 1459 1.80 1528 1.95 1603 2.17 1666 2.37
2300 1130 1.26 1202 1.29 1248 1.38 1358 1.69 1410 1.72 1488 1.93 1561 2.13 1637 2.35 1710 2.54
2400 1174 1.37 1237 1.41 1292 1.55 1392 1.81 1460 1.90 1532 2.14 1584 2.28 1671 2.55 1756 2.70
2500 1201 1.48 1272 1.53 1335 1.71 1427 1.94 1518 2.16 1575 2.35 1633 2.53 1698 2.72 — —
2600 1246 1.62 1320 1.68 1368 1.81 1458 2.06 1562 2.42 1620 2.59 1675 2.77 — — — —
2700 1285 1.75 1361 1.82 1400 1.91 1490 2.19 1602 2.64 1666 2.85 — — — — — —
2800 1304 1.87 1402 1.95 1439 2.08 1543 2.43 1642 2.86 — — — — — — — —
2900 1345 2.07 1446 2.16 1477 2.16 1585 2.65 — — — — — — — — — —
3000 1378 2.26 1489 2.36 1529 2.52 1598 2.73 — — — — — — — — — —
581B072 (6 TONS) — HIGH-STATIC MOTOR
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1800 978 0.66 1063 0.82 1147 0.97 1248 1.20 1322 1.33
1900 1023 0.78 1097 0.91 1175 1.11 1266 1.29 1356 1.47
2000 1068 0.90 1132 1.01 1218 1.23 1303 1.41 1397 1.52
2100 1115 1.00 1180 1.17 1261 1.35 1340 1.53 1428 1.66
2200 1159 1.15 1214 1.28 1310 1.52 1375 1.63 1459 1.80
2300 1202 1.29 1248 1.38 1358 1.69 1410 1.72 1488 1.93
2400 1237 1.41 1292 1.55 1392 1.81 1460 1.90 1532 2.14
2500 1272 1.53 1335 1.71 1427 1.94 1518 2.16 1575 2.35
2600 1320 1.68 1368 1.81 1458 2.06 1562 2.42 1620 2.59
2700 1361 1.82 1400 1.91 1490 2.19 1602 2.64 1666 2.85
2800 1402 1.95 1439 2.08 1543 2.43 1642 2.86 1775 3.62
2900 1446 2.16 1477 2.16 1585 2.65 1753 3.58 — —
3000 1489 2.36 1529 2.52 1598 2.73 1767 3.69 — —
581B072 (6 TONS) — HIGH-STATIC MOTOR (cont)
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
1800 1395 1.46 1475 1.56 1542 1.71 1607 1.94 1667 2.16
1900 1430 1.58 1504 1.69 1556 1.82 1621 2.06 1682 2.30
2000 1459 1.67 1532 1.82 1588 1.97 1655 2.23 1717 2.49
2100 1489 1.80 1567 1.99 1626 2.16 1694 2.44 1758 2.73
2200 1528 1.95 1603 2.17 1666 2.37 1736 2.68 — —
2300 1561 2.13 1637 2.35 1710 2.54 1782 2.87 — —
2400 1584 2.28 1671 2.55 1756 2.70 — — — —
2500 1633 2.53 1698 2.72 1779 3.13 — — — —
2600 1675 2.77 1768 3.26 — — — — — —
2700 1776 3.45 — — — — — — — —
2800 — — — — — — — — — —
2900 — — — — — — — — — —
3000 — — — — — — — — — —
Bhp — Brake Horsepower Input to Fan
FIOP — Factory-Installed Option
