PERFORMANCE DATA (cont)
FAN PERFORMANCE — VERTICAL DISCHARGE UNITS (cont)
LEGEND
NOTES:
1. Boldface indicates field-supplied drive required. (See Note 3.)
2. indicates field-supplied motor and drive required.
3. Motor drive range is 840 to 1085 rpm for standard motors, 860 to 1080 rpm
for high-static motors. All other rpms require a field-supplied drive.
4. Values include losses for filters, unit casing, and wet coils. See page 40 for
accessory/FIOP static pressure information.
5. Maximum continuous bhp is 2.90 for standard motors, 4.20 for high-static
motors. Extensive motor and electrical testing on these units ensures that
the full range of the motor can be utilized with confidence. Using your fan
motors up to the ratings shown will not result in nuisance tripping or prema-
ture motor failure. Unit warranty will not be affected. See Evaporator-Fan
Motor Data tables on pages 41 and 42 for additional information.
6. Use of a field-supplied motor may affect wire sizing. Contact your Bryant
representative to verify.
581B102 (8 1 /
2
TONS) — STANDARD MOTOR
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2550 559 0.72 634 0.97 700 1.21 759 1.48 814 1.74 864 2.01 915 2.34 968 2.81
2600 567 0.75 641 1.00 706 1.25 764 1.52 819 1.79 869 2.06 918 2.37 973 2.81
2700 582 0.83 655 1.08 719 1.34 776 1.61 831 1.89 880 2.17 927 2.47 976 2.84
2800 598 0.90 670 1.17 732 1.43 789 1.71 842 2.00 892 2.29 938 2.58 983 2.92
2900 614 0.98 684 1.25 745 1.53 802 1.81 854 2.11 903 2.42 949 2.71 993 3.03
3000 630 1.07 690 1.35 759 1.63 815 1.92 866 2.23 915 2.54 961 2.85 1003 3.17
3100 646 1.16 714 1.45 773 1.74 828 2.04 878 2.35 926 2.67 972 3.00 1016 3.32
3200 662 1.26 729 1.55 787 1.86 841 2.16 891 2.48 938 2.81 983 3.14 1026 3.47
3300 679 1.36 744 1.66 801 1.98 854 2.29 904 2.61 950 2.95 995 3.30 — —
3400 695 1.47 759 1.78 816 2.10 867 2.42 917 2.75 963 3.10 1007 3.45 — —
3500 712 1.59 774 1.90 830 2.23 881 2.56 930 2.90 976 3.25 — — — —
3600 729 1.71 790 2.03 845 2.37 895 2.71 943 3.05 988 3.41 — — — —
3700 745 1.84 805 2.17 860 2.52 909 2.87 956 3.22 — — — — — —
3750 754 1.91 813 2.24 868 2.59 917 2.95 963 3.30 — — — — — —
3800 762 1.98 821 2.31 875 2.66 924 3.03 970 3.38 — — — — — —
3900 779 2.12 836 2.46 890 2.82 938 3.19 — — — — — — — —
4000 796 2.27 852 2.61 905 2.98 953 3.37 — — — — — — — —
4100 813 2.42 868 2.78 920 3.15 — — — — — — — — — —
4200 830 2.59 884 2.95 935 3.33 — — — — — — — — — —
4250 839 2.68 890 3.04 — — — — — — — — — — — —
4300 847 2.76 900 3.13 — — — — — — — — — — — —
581B102 (8 1 /
2
TONS) — HIGH-STATIC MOTOR
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2550 559 0.72 634 0.97 700 1.21 759 1.48 814 1.74
2600 567 0.75 641 1.00 706 1.25 764 1.52 819 1.79
2700 582 0.83 655 1.08 719 1.34 776 1.61 831 1.89
2800 598 0.90 670 1.17 732 1.43 789 1.71 842 2.00
2900 614 0.98 684 1.25 745 1.53 802 1.81 854 2.11
3000 630 1.07 690 1.35 759 1.63 815 1.92 866 2.23
3100 646 1.16 714 1.45 773 1.74 828 2.04 878 2.35
3200 682 1.26 729 1.55 787 1.86 841 2.16 891 2.48
3300 679 1.36 744 1.66 801 1.98 854 2.29 904 2.61
3400 695 1.47 759 1.78 816 2.10 867 2.42 917 2.75
3500 712 1.59 774 1.90 830 2.23 881 2.56 930 2.90
3600 729 1.71 790 2.03 845 2.37 895 2.71 943 3.05
3700 745 1.84 805 2.17 860 2.52 909 2.87 956 3.22
3750 754 1.91 813 2.24 868 2.59 917 2.95 963 3.30
3800 762 1.98 821 2.31 875 2.66 924 3.03 970 3.38
3900 779 2.12 836 2.46 890 2.82 938 3.19 981 3.65
4000 796 2.27 852 2.61 905 2.98 953 3.37 996 3.85
4100 813 2.42 868 2.78 920 3.15 974 3.74 1019 4.28
4200 830 2.59 884 2.95 935 3.33 990 3.96 1036 4.52
4250 839 2.68 890 3.04 965 3.88 1022 4.61 1069 5.27
4300 847 2.76 900 3.13 976 3.99 1034 4.74 1081 5.42
581B102 (8 1 /
2
TONS) — HIGH-STATIC MOTOR (cont)
AIRFLOW
(Cfm)
EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp Rpm Bhp
2550 864 2.01 915 2.34 968 2.81 991 3.02 1012 3.21
2600 869 2.06 918 2.37 973 2.81 996 3.02 1017 3.21
2700 880 2.17 927 2.47 976 2.84 999 3.05 1021 3.25
2800 892 2.29 938 2.58 983 2.92 1006 3.13 1028 3.34
2900 903 2.42 949 2.71 993 3.03 1017 3.25 1038 3.46
3000 915 2.54 961 2.85 1003 3.17 1027 3.40 1049 3.62
3100 926 2.67 972 3.00 1016 3.32 1040 3.56 1062 3.80
3200 938 2.81 983 3.14 1026 3.47 1050 3.72 1073 3.97
3300 950 2.95 995 3.30 1022 3.58 1046 3.84 1069 4.09
3400 963 3.10 1007 3.45 1034 3.74 1059 4.01 1081 4.27
3500 976 3.25 1007 3.56 1034 3.86 1058 4.15 1081 4.42
3600 988 3.41 1019 3.74 1047 4.05 1071 4.35 1094 4.63
3700 992 3.59 1023 3.94 1050 4.27 1075 4.58 1098 4.88
3750 999 3.68 1030 4.04 1058 4.38 1083 4.70 1106 5.00
3800 1006 3.77 1038 4.14 1066 4.48 1091 4.81 1114 5.12
3900 1017 4.07 1049 4.46 1077 4.84 1103 5.19 1127 5.53
4000 1034 4.30 1066 4.71 1095 5.11 1121 5.48 1145 5.84
4100 1057 4.77 1090 5.24 1119 5.67 1146 6.09 1170 6.49
4200 1074 5.05 1108 5.54 1138 6.00 1165 6.44 1190 6.86
4250 1109 5.88 1143 6.45 1174 6.98 1202 7.50 1228 7.98
4300 1121 6.05 1156 6.64 1188 7.19 1216 7.72 1242 8.22
Bhp — Brake Horsepower Input to Fan
FIOP — Factory-Installed Option
