Pipework Schematics
Legend
Centrifugal Fan
Axial Fan
Scroll Compressor
Three Way Solenoid Valve
Sight Glass
Thermostatic Expansion
Valve
Filter Drier
Normally Closed Solenoid
Valve
Check Valve
Shut Off Valve
Bypass Balancing Valve
Three Way Regulating
Valve
Three Way regulating valve
with head pressure control
Bleed Valve
Binder Point
Liquid Receiver
Plate Condenser
