Performance Data – Condensers
Standard Condenser Fan
Mean Condensing
Ambient
Temperature °C
25°C
30°C
35°C
40°C
45°C
48°C
Output
(kW)
Output
(kW)
Output
(kW)
Output
(kW)
Output
(kW)
Output
(kW)
CR12
35
8.8
3.3
-
-
-
-
40
13.8
8.8
3.4
-
-
-
45
19.0
14.0
8.9
3.6
-
-
50
24.4
19.2
14.1
9.1
3.8
-
55
29.8
24.7
19.5
14.4
9.3
4.1
CR16
35
11.9
5.0
-
-
-
-
40
18.2
12.0
5.2
-
-
-
45
24.7
18.4
12.1
5.4
-
-
50
31.3
25.0
18.6
12.3
5.6
-
55
38.2
31.8
25.4
19.0
12.6
6.5
CR22
35
15.4
6.2
-
-
-
-
40
24
15.5
6.4
-
-
-
45
32.8
24.2
15.7
6.7
-
-
50
41.7
33.1
24.6
16.0
7.0
-
55
51.0
42.3
33.7
25.1
16.4
7.7
CR26
35
19.2
7.8
-
-
-
-
40
29.9
19.4
8.0
-
-
-
45
40.9
30.3
19.6
8.4
-
-
50
52.1
41.4
30.7
20.0
8.8
-
55
63.5
52.9
42.1
31.4
20.5
9.9
CR30
35
19.8
8.1
-
-
-
-
40
30.6
20.0
8.4
-
-
-
45
41.7
30.9
20.2
8.7
-
-
50
53.1
42.1
31.3
20.5
9.2
-
55
64.8
53.8
42.8
31.9
21.0
9.8
CR35
35
25.4
10.5
-
-
-
-
40
39.4
25.7
10.9
-
-
-
45
53.6
39.7
26.0
11.3
-
-
50
68.1
54.2
40.3
26.4
11.8
-
55
83.1
69.0
55.0
41.1
27
12.9
CR50
35
33.7
13.7
-
-
-
-
40
52.6
34.0
14.2
-
-
-
45
71.7
53.1
34.4
14.8
-
-
50
91.3
72.5
53.8
35.1
15.5
-
55
111.5
92.6
73.7
54.8
35.9
16.9
CR60
35
42.3
65.9
-
-
-
-
40
65.9
42.7
17.9
-
-
-
45
89.8
66.6
43.2
18.6
-
-
50
114..3
91.0
67.6
44.0
19.5
-
55
139.5
116.0
92.5
68.9
45.1
20.3
(1)
Output kW refers to the condenser heat rejection.
