Installation, Maintenance and Commissioning Manual :6877419 02/2013
Mechanical Data – C0C0
SC19D033-C0C0-0
SC19D038-C0C0-0
SC19D045-C0C0-0
Capacity
(1)
Nom Cooling (Gross)
kW
46.5
51.4
58.6
Fan Gain
(3)
kW
0.66
1.0
1.7
Dimensions - W x D x H
mm
1985 x 890 x 1980
1985 x 890 x 1980
1985 x 890 x 1980
Weight - Machine / Operating
kg
730 / 790
730 / 790
730 / 790
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material/Colour
Frame: Anodised Aluminium Frame with Black Nylon Corners
Cooling Coil
Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1 (Modulated) / 1
Water volume
l
54.5
54.5
54.5
Water flow rate
l/s
2.67
2.85
3.16
Pressure drop
kPa
34.83
35.63
37.12
Fan & Motor
Backwards Curved, Centrifugal direct drive
Motor Type
EC
EC
EC
Quantity x Motor Size
kW
2 x 2.3
2 x 2.3
2 x 2.3
Speed @25Pa ESP/maximum ESP
rpm
964 / 1360
1117 / 1360
1340 / 1360
Maximum ESP
Pa
438
302
49
Nominal Airflow
m³/s
3.7
4.3
5.1
Connections
Water Inlet / Outlet
mm
35
35
35
Condensate Drain Hose
mm
22
22
22
Filtration
Disposable to BS EN 779-G4-600
Quantity
3
3
3
OPTIONAL EXTRAS
Electric Heating (Total)
kW
31.5
31.5
31.5
Humidifier
Capacity
kg/hr
15
15
15
Feed/Drain
3/4" BSPF Braided flexible hose / 19mm hose connection
Condensate Pump
Head
m
10.8
10.8
10.8
Flow
l/m
5
5
5
Drain
10mm Stainless Steel Stub Connection
First upgrade Fan Motor - EC Motor
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size
kW
2 x 3.1
2 x 3.1
2 x 3.1
Speed @ 25Pa / Maximum ESP
rpm
986 / 1520
1145 / 1520
1364 / 1520
Maximum ESP
Pa
589
453
216
Fan Gain
(3)
kW
0.65
1.03
1.73
Second upgrade Fan Motor - EC Motor
Backwards Curved, Centrifugal direct drive
Quantity x Motor Size
kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
N/A
N/A
N/A
Maximum ESP
Pa
N/A
N/A
N/A
Fan Gain
(3)
kW
N/A
N/A
N/A
Low Pressure Hot Water
(2)
Copper Tube/Aluminium Fin
Capacity Gross
kW
22.7
23.9
26.1
Water Flow (Nominal)
l/s
0.51
0.53
0.58
Pressure drop
kPa
9.4
9.7
10.1
LPHW Connection Sizes
mm
22
22
22
(1) Entering air 24°C/ 45% RH water 7°C/ 12°C
(2) Based upon low pressure hot water 82°C inlet/71°C outlet. Air on 20°C
(3) Fan gain based on 25Pa ESP @ nominal air volume. Fan gain figure will change as airflow and ESP change.
