Page 132: Electrical data – w2f0
SmartCool
TM
- D
Precision Air Conditioning
132
Precision Air Conditioning
Installation, Maintenance and Commissioning Manual :6877419 02/2013
Electrical Data – W2F0
SC19D033-W2F0-0
SC19D038-W2F0-0
SC19D045-W2F0-0
Standard Dry Cooler Match
1 x DR40
1 x DR55
1 x DR55
Unit Data Full Function- W2F0
Nominal Run Amps
(1)
A
54.3
57.2
59
Maximum Start Amps
A
115.8
132.8
145.8
Recommended Mains Fuse Size
A
63
80
80
Max Mains Incoming Cable Size
mm²
35
35
35
Mains Supply
V
400V / 3PH + N / 50Hz
Control circuit
VAC
24
24
24
Unit Data Cooling Only - W2F0
Nominal Run Amps
A
32.5
38.2
42
Maximum Start Amps
A
94
113.9
128.7
Recommended Mains Fuse Size
A
40
50
50
Evaporator Fan Motor - Per Fan
Motor Type
(2)
EC
EC
EC
Quantity x Motor Size
kW
2 x 2.2
2 x 2.2
2 x 2.2
Full Load Amps
A
3.3
3.3
3.3
Locked Rotor Amps
A
3.3
3.3
3.3
Compressor 1, Circuit 1
Motor Size
(3)
kW
4.6
5.55
6.31
Nominal Run Amps
A
8.5
11.4
13.3
Locked Rotor Amps
A
70
87
100
Type of Start
Direct On Line
Compressor 2, Circuit 1
Motor Size
(3)
kW
4.6
5.55
6.3
Nominal Run Amps
A
8.5
11.4
13.3
Locked Rotor Amps
A
70
87
100
Type of Start
Direct On Line
Standard Dry Cooler Match - Motor Per Fan
AC
AC
EC
Quantity x Motor Size
kW
2 x 0.6
3 x 0.6
3 x 0.6
Full Load Amps
A
2.62
2.62
2.62
OPTIONAL EXTRAS
Electric Heating
Number of stage of Reheat
2
2
2
Number of Elements
6
6
6
Rating (Total)
kW
21
21
21
Current Per Phase
A
30.3
30.3
30.3
Humidifier
Capacity
kg/hr
8
8
8
Rating
kW
6
6
6
Full Load Amps
A
8.7
8.7
8.7
First upgrade Motor - EC Motor - Per Fan
Quantity x Motor Size
(2)
kW
2 x 3.1
2 x 3.1
2 x 3.1
Full Load Amps
A
4.8
4.8
4.8
Locked Rotor Amps
A
4.8
4.8
4.8
Second upgrade Motor - EC Motor - Per Fan
Quantity x Motor Size
(2)
kW
N/A
N/A
N/A
Full Load Amps
A
N/A
N/A
N/A
Locked Rotor Amps
A
N/A
N/A
N/A
Standard Dry Cooler Match - EC Motor-Per
Fan
Quantity x Motor Size
(2)
kW
2 x 0.73
3 x 0.73
3 x 0.73
Full Load Amps
A
3.3
3.3
3.3
Dry Cooler Match - SCAF Fan
Quantity x Motor Size
(2)
kW
2 x 1.4
3 x 1.4
3 x 1.4
Full Load Amps
A
6
6
6
(1) Values given for function units with standard selections for heating, humidification, supply air fans 7°C evaporating and 54.4°C condensing
(2) Stated motor power is based on maximum electrical power absorbed
(3) Values are per compressor
