Cooling Duties – Free cooling
Chilled Water Inlet Temperatures
Model
Air On
5 °C /10°C
7°C /12°C
8°C / 14°C
10°C / 16°C
5.5°C/ 14.5°C
Temp (°C) %RH
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
TC
(kW)
SC
(kW)
SC19D033-W2F0-0
1 x DR40
22 / 50
68.2
54.8
49.3
44.9
40.2
40.2
31.4
31.4
21.3
21.3
24 / 45
77.8
63.1
61.6
55.9
49.1
49.1
40.9
40.9
48.1
48.1
26 / 40
86.2
71.4
70.0
64.3
57.7
57.7
49.7
49.7
58.1
58.1
SC19D038-W2F0-0
1 x DR55
22 / 50
75.5
61.7
55.1
51.3
45.4
45.4
35.6
35.6
22.2
22.2
24 / 45
86.2
71.1
67.9
63.1
55.3
55.3
46.1
46.1
54.8
54.8
26 / 40
95.5
80.6
74.7
68.8
65.0
65.0
56.0
56.0
65.8
65.8
SC19D045-W2F0-0
1 x DR55
22 / 50
85.0
71.1
62.3
62.3
52.2
52.2
41.2
41.2
50.0
50.0
24 / 45
97.3
81.9
74.4
69.8
63.6
63.6
53.0
53.0
63.5
63.5
26 / 40
108.1
92.9
85.2
80.8
74.7
74.7
64.3
64.3
75.8
75.8
SC19D064-W2F0-0
1 x DR95
22 / 50
85.0
71.1
62.3
62.3
52.2
52.2
41.2
41.2
50.0
50.0
24 / 45
97.3
81.9
74.4
69.8
63.6
63.6
53.0
53.0
63.5
63.5
26 / 40
108.1
92.9
85.2
80.8
74.7
74.7
64.3
64.3
75.8
75.8
SC19D070-W2F0-0
1 x DR95 (EC)
22 / 50
85.0
71.1
62.3
62.3
52.2
52.2
41.2
41.2
50.0
50.0
24 / 45
97.3
81.9
74.4
69.8
63.6
63.6
53.0
53.0
63.5
63.5
26 / 40
108.1
92.9
85.2
80.8
74.7
74.7
64.3
64.3
75.8
75.8
SC19D076-W2F0-0
1 x DR95 (EC)
22 / 50
85.0
71.1
62.3
62.3
52.2
52.2
41.2
41.2
50.0
50.0
24 / 45
97.3
81.9
74.4
69.8
63.6
63.6
53.0
53.0
63.5
63.5
26 / 40
108.1
92.9
85.2
80.8
74.7
74.7
64.3
64.3
75.8
75.8
SC25D045-W2F0-0
1 x DR55
22 / 50
100.7
79.5
78.0
69.4
60.3
60.3
48.6
48.6
62.0
62.0
24 / 45
114.1
91.2
91.4
81.1
72.4
72.4
61.0
61.0
79.5
76.0
26 / 40
126.0
103.0
103.1
92.9
84.3
84.3
73.1
73.1
91.3
84.7
SC25D050-W2F0-0
1 x DR70
22 / 50
109.2
86.9
84.2
75.8
65.8
65.8
53.0
53.0
67.8
67.8
24 / 45
123.8
99.7
98.8
88.7
79.0
79.0
66.5
66.5
84.5
80.3
26 / 40
136.7
112.6
111.6
101.6
92.0
92.0
79.8
79.8
98.9
93.5
SC25D055-W2F0-0
1 x DR70
22 / 50
117.2
94.0
90.1
82.1
71.1
71.1
57.3
57.3
73.4
73.4
24 / 45
132.9
107.9
105.8
96.0
85.4
85.4
71.9
71.9
90.6
87.8
26 / 40
147.0
122.0
119.7
110.1
99.6
99.6
86.3
86.3
106.1
102.2
SC25D067-W2F0-0
1 x DR95
22 / 50
117.2
94.0
90.1
82.1
71.1
71.1
57.3
57.3
73.4
73.4
24 / 45
132.9
107.9
105.8
96.0
85.4
85.4
71.9
71.9
90.6
87.8
26 / 40
147.0
122.0
119.7
110.1
99.6
99.6
86.3
86.3
106.1
102.2
SC25D073-W2F0-0
1 x DR95
22 / 50
117.2
94.0
90.1
82.1
71.1
71.1
57.3
57.3
73.4
73.4
24 / 45
132.9
107.9
105.8
96.0
85.4
85.4
71.9
71.9
90.6
87.8
26 / 40
147.0
122.0
119.7
110.1
99.6
99.6
86.3
86.3
106.1
102.2
SC25D080-W2F0-0
1 x DR95 (EC)
22 / 50
117.2
94.0
90.1
82.1
71.1
71.1
57.3
57.3
73.4
73.4
24 / 45
132.9
107.9
105.8
96.0
85.4
85.4
71.9
71.9
90.6
87.8
26 / 40
147.0
122.0
119.7
110.1
99.6
99.6
86.3
86.3
106.1
102.2
SC31D055-W2F0-0
1 x DR70
22 / 50
117.0
90.1
92.1
78.7
71.1
67.7
56.6
56.6
82.6
73.8
24 / 45
132.0
103.0
107.0
91.6
91.0
91.0
70.1
70.1
99.8
88.0
26 / 40
145.2
116.1
120.1
104.7
98.7
91.8
83.4
83.4
114.5
101.9
SC31D065-W2F0-0
1 x DR95
22 / 50
133.3
103.7
104.5
90.6
79.8
79.8
64.9
64.9
93.1
84.8
24 / 45
150.5
118.7
121.6
105.6
97.4
92.6
80.5
80.5
112.6
101.0
26 / 40
165.8
133.8
136.7
120.8
112.7
107.8
95.9
95.9
129.3
117.1
SC31D075-W2F0-0
1 x DR95
22 / 50
148.7
116.8
116.1
102.1
89.6
89.6
72.8
72.8
102.8
95.2
24 / 45
168.0
133.7
135.2
119.1
107.0
107.0
90.5
90.5
124.4
113.6
26 / 40
185.1
151.0
152.1
136.3
124.2
124.2
107.9
107.9
143.1
131.7
SC31D077-W2F0-0
1 x DR95
22 / 50
148.7
116.8
116.1
102.1
89.6
89.6
72.8
72.8
102.8
95.2
24 / 45
168.0
133.7
135.2
119.1
107.0
107.0
90.5
90.5
124.4
113.6
26 / 40
185.1
151.0
152.1
136.3
124.2
124.2
107.9
107.9
143.1
131.7
SC31D080-W2F0-0
1 x DR95 (EC)
22 / 50
148.7
116.8
116.1
102.1
89.6
89.6
72.8
72.8
102.8
95.2
24 / 45
168.0
133.7
135.2
119.1
107.0
107.0
90.5
90.5
124.4
113.6
26 / 40
185.1
151.0
152.1
136.3
124.2
124.2
107.9
107.9
143.1
131.7
SC31D083-W2F0-0
1 x DR95 (EC)
22 / 50
148.7
116.8
116.1
102.1
89.6
89.6
72.8
72.8
102.8
95.2
24 / 45
168.0
133.7
135.2
119.1
107.0
107.0
90.5
90.5
124.4
113.6
26 / 40
185.1
151.0
152.1
136.3
124.2
124.2
107.9
107.9
143.1
131.7
TC = Total Cooling, SC =Sensible Cooling, THR= Total Heat of Rejection
(1) All data quoted is gross, Capacities based on water
DT stated. With Constant water flow systems the free cooling performance may be reduced if the flow
through the condenser is lower than required for the free cooling. Please contact Airedale for performance figures.
(2) Deduct fan gain for net duties, refer to Mechanical Data
(3) All data quoted is based upon 100% water.
