GENERAL PUMP
A member of the Interpump Group
SM SERIES
Page 39
4. REPAIR TOOLS
Pump maintenance may be carried out using simple tools for assembling and disassembling components.
The following tools are available:
For Assembly:
• Shaft (connecting rod interlocking) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27566200
• Bearing on crankshaft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27604700
• Pinion bearing on reduction gear box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27604900
• Crankshaft bearing on reduction gear box . . . . . . . . . . . . . . . . . . . . . . . . . F27605000
• Plunger guide oil seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27605300
• Bearing on pinion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27604800
• Pinion seal ring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27605200
• Plunger bushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27921100 (SM14)
F27921200 (SM16)
F27931300 (SM18)
F27911200 (SM20)
F27911400 (SM22)
F27911500 (SM24)
• HP seal packings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F27673200 (SM14,16,SM18)
• Heads / Liners spacers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .F27540200
For Disassembly:
• Plunger guid oil seal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27918500
• Shaft (connecting rod interlocking) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27566200
• Valve housing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F034300020
• Heads / Liners spacer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . F27540200
Ref 300894 Rev.A
06-12
