SM SERIES
Position the 3 grub screws or M8 threaded screws (1, fig. 28) with the function of extractors in the holes.
Remove the crankshaft casing from the PTO side (1, fig. 31).
Page 11 Ref 300894 Rev.A
06-12
Slowly screw in the 3 M8 screws (1, fig. 29) to prevent the cover from tilting too far and getting locked in the
housing. Remove the bearing cover while supporting the shaft to prevent damage. (1. fig. 30).
