GENERAL PUMP
A member of the Interpump Group
SM SERIES
The crankshaft must always be assembled with the PTO on the opposite side
with respect to the 1/2” holes for the oil discharge plugs on the pump casing (1, fig. 51).
Page 16
Insert the shaft from the PTO side, taking care not to hit the previously assembled connecting rod shanks
(1, fig. 48) and (1, fig. 49).
Ref 300894 Rev.A
06-12
Block the three units with the use of special tool part #F27566200 (1, fig. 32)
Preassemble the ring inside the crankshaft bearings (on both sides of the shaft down to the stroke) using
special tool part #F27604700 (1, fig. 46) (1, fig. 47).
The inner and outer rings of the bearings must be reassembled keeping the same
coupling with which they were disassembled.
