Chapter 6 Specification
Section 1 Plug and Play
The Mobile Monitor conforms to VESA DDC standard and supports VESA DDC2. DDC2B
is a bi-directional data channel based on I
2
C protocol. The host can request EDID infor-
mation over the DDC2B channel. The Mobile Monitor is able to inform the host system
of its identity, and depending on the level of DDC used, communicate additional infor-
mation about its display capabilities.
Section 2 Standard Default Modes
Section 3 Troubleshooting
1. With Digital Video cable
20
Display Mode Resolution
1 MAC 640x480 60 Hz
2 VESA 720x400 60 Hz
3 SVGA 800x600 56 Hz
4 SVGA 800x600 60 Hz
5 XGA 1024x768 60 Hz
6 WXGA 1366x768 60 Hz
Problem Screen Display Solution
No screen
Please check if the video and USB-Powered plug
is correctly connected to the Mobile Monitor’s
video power port.
Blank screen
Please check if USB-Powered cable is connected
to a 5V DC power source.
Please adjust Brightness and Contrast settings, or
reset them to factory default via OSD.
OSD shows “No
Signal” warning
Please check if Digital Video cable is correctly
connected to Mobile Monitor’s video input port
and computer’s HDMI output port.
