Service Manual Repair procedures 63
Interface chassis
The Interface Chassis is available either with or without the Nurse Call option.
Rear chassis
The Rear Chassis contains the following components:
• Recharger Board
• Side panels (right and left)
• NIBP pump
• NIBP tubing
• NIBP valves
Standard Interface Chassis Interface Chassis with Nurse Call Option
Nurse Call
Option
connector
0696-12
Rear Chassis
Recharger Board
Right Side Panel
Left Side Panel
