Service Manual Field Replaceable Units (FRUs) 131
SCP BOARD, NELLCOR MP-203 ONLY, U11 64K PROM 020-0476-00
SCP BOARD, NELLCOR / MASIMO, U303 128K PROM 031-0133-03
FRONT CHASSIS, SPO2 ONLY 020-0122-01
REAR CHASSIS, SPO2 ONLY 020-0123-01
MOUNTING SCREWS WITH WASHERS 020-0126-00
SPEAKER PANEL ASSEMBLY 020-0125-01
SPO2 CONNECTOR PANEL, NELLCOR MP-203 (W/O LABEL) 020-0190-00
SPO2 CONNECTOR PANEL, NELLCOR MP-405 010-0210-02
SPO2 CONNECTOR PANEL, NELLCOR MP-507 010-0231-00
SPO2 CONNECTOR PANEL, MASIMO MS3 - MINI DIN CONNECTOR WITH SHROUD 010-0208-00
SPO2 CONNECTOR PANEL, MASIMO MS3 WITH MASIMO STYLE CONNECTOR 010-0236-00
LOCKING "D" CONNECTOR, SPO2 PANEL 630-0038-00
CO
2
option, Mainstream/Sidestream
MSP BOARD, WITH MCO2, MP-203 ONLY, U11 64K PROM, D/E/G SERIES 020-0580-00
MSP BOARD, W/O MCO2, MP-203 ONLY, U11 64K PROM, D/G SERIES ONLY 031-0058-51
MSP BOARD, WITH MCO2, MS3 / ALL NELLCOR, U1 128K PROM, D/G SERIES ONLY 031-0058-03
MSP BOARD, W/O MCO2, MS3 / ALL NELLCOR, U1 128K PROM, D/G SERIES ONLY 031-0058-53
CO
2
option, Mainstream
CONNECTOR PANEL, CO2, W/O BRACKET 020-0582-00
MAINSTREAM CO2 SENSOR EXCHANGE (CO2 sensor listed is exchange for reworked sensor II, 90
day warranty) 108-0502-00
MAINSTREAM CO2 SENSOR TRADE-IN (CO2 sensor listed is trade-in for new sensor II, one year
warranty) 008-0502-00
CO
2
option, Sidestream
SSP BOARD (Requires Service Center calibration) 020-0574-00
STICK BOARD (Requires Service Center calibration) 031-0094-02
EXTENDER BOARD 031-0092-00
FRONT PANEL, EMP, SSCO2 020-0575-00
Option interconnect cables
CABLE, POWER HARNESS, EM 660-0090-00
CABLE, PROPAQ P4 TO PCP-P140 010-0055-00
CABLE, PROPAQ P4 TO SCP/MSP-P1 010-0048-00
CABLE, SCP-P4 TO PCP-P140 010-0054-00
CABLE, MSP-P4 TO PCP-P140/KEYPAD TO PCP-P400 010-0056-00
Labels, all language applications
LABEL, MODEL 242 640-0506-00
LABEL, MODEL 244 640-0507-00
LABEL, MODEL 246 640-0508-00
LABEL, RIGHT SIDE PANEL 640-0325-00
Replacement part description Part number
