6-24 MAX 6000/3000 Network Configuration Guide
Configuring X.25
Configuring X.25 PAD users from RADIUS
Configuring X.25 PAD users from RADIUS
Using DNIS/CLID, you can now authenticate X.25 PAD users by means of RADIUS. This
feature is useful when you require more than 3 X.25 connection profiles. A RADIUS user can
set the attribute Ascend-X25-Pad-X3-Profile to Custom and use the
Ascend-X25-Pad-Parameters attribute to configure the PAD X.3 parameters on a per-user
basis. However, when the PAD users are configured from RADIUS, the ability to store a
30 48 Timer expired
31 49 For incoming call (or for DTE timer expired for call
request)
32 50 For clear indication (or for DTE timer expired or
retransmission count surpassed for clear request)
33 51 For reset indication (or for DTE timer expired or
retransmission count surpassed for reset request)
34 52 For restart indication (or for DTE timer expired or
retransmission count surpassed for restart request)
40 64 Call setup, call clearing, or registration problem
41 65 Facility/registration code not allowed
42 66 Facility parameter not allowed
43 67 Invalid called address
44 68 Invalid calling address
45 69 Invalid facility/registration length
46 70 Incoming call barred
47 71 No logical channel available
48 72 Call collision
49 73 Duplicate facility requested
4A 74 Nonzero address length
4B 75 Nonzero facility length
4C 76 Facility not provided when expected
Table 6-6. X.25 diagnostic field values (continued)
Hex
value Dec
value Diagnostic
