Appendix B. SCSI Cable and Terminator
Requirements
To operate correctly, the Spectra 12000 library must meet certain
requirements which are discussed in the following sections:
SCSI Cable Requirements
The following table lists the recommended specifications for a SCSI
cable:
Cable Feature
Requirement
Standard Construction
68 conductors (34 twisted pairs with drain wire and shield)
Primary Conductors
Insulated per UL Style 1589
Gauge: #28 AWG minimum stranded (7/34) annealed, tinned copper
Insulation: Polypropylene (176
°
F) (80
°
C) 0.010 inch nominal
Shielding
80% minimum tinned copper braid over aluminum/mylar foil
Outer Jacket
Insulated per UL Style 2919, polyvinyl chloride (PVC) (176
°
F) (80
°
C)
Voltage Rating
30 VAC
Impedance
100 Ohms ±10% @ 1.5 MHz
Grounding
Case to case grounding
Connector
68-contact AMP Amplimate 0.050 male, shielded, SCSI-3 connector
