Icom IC-7700 User Manual

Page 94

5-6

Scope set mode (continued)

FUNCTIONS FOR RECEIVE

Select the sweep speed for the ±50 kHz span selec-
tion from SLOW, MID and FAST.

(

50k)

FAST

Select the sweep speed for the ±100 kHz span selec-
tion from SLOW, MID and FAST.

(

100k)

FAST

Select the sweep speed for the ±250 kHz span selec-
tion from SLOW, MID and FAST.

(

250k)

FAST

Set the scope edge frequencies for fixed mode for
bands below 1.6 MHz.

• Set the frequencies within 0.030 to 1.600 MHz

range in 1 kHz steps.

Up to 500 kHz band width can be specified, so
either edge frequency will be set to the difference
between higher and lower frequencies from 5 to
500 kHz automatically while setting another edge
frequency.

Fixed Edges ( 0.03 –

1.60)

0.750

1.250

–

MHz

Set the scope edge frequencies for fixed mode scope
when the 1.6 to 2 MHz band is selected.

• Set the frequencies within 1.600 to 2.000 MHz

range in 1 kHz steps.

( 1.60 –

2.00)

1.800

2.000

–

MHz

Set the scope edge frequencies for fixed mode scope
when the 2 to 6 MHz band is selected.

• Set the frequencies within 2.000 to 6.000 MHz

range in 1 kHz steps.

( 2.00 –

6.00)

3.500

4.000

–

MHz

Set the scope edge frequencies for fixed mode scope
when the 6 to 8 MHz band is selected.

• Set the frequencies within 6.000 to 8.000 MHz

range in 1 kHz steps.

( 6.00 –

8.00)

7.000

7.300

–

MHz

Select the sweep speed for the ±25 kHz span selec-
tion from SLOW, MID and FAST.

(

25k)

FAST
