3-11
D D Meter type selection
A total of 3 meter types are available in the IC-7700—
Standard, Edgewise and Bar meters.
Follow the instructions below for the meter type selec-
tion.
q Push several times to return to normal
screen, if necessary.
w Push [F-7•SET], then push [F-3•DISP] to select dis-
play set mode.
e Push [F-1• Y ] or [F-2• Z ] to select “Meter type (Nor-
mal Screen)” item.
r Rotate the main dial to select the desired meter type
from “Standard,” “Edgewise” and “Bar.”
t Push to exit display set mode.
• Edgewise meter
• Bar meter
EXIT/SET
EXIT/SET
3
BASIC OPERATIONS
The IC-7700 has built-in voice synthesizer to an-
nounce the frequency, mode, etc. (S-meter level can
also be announced—p. 12-15) in clear, electroni-
cally-generated voice, in English (or Japanese).
➥
Push to announce the currently se-
lected frequency, etc.
• Push and hold for 1 sec. to additionally an-
nounce the selected mode.
➥
Pushing a mode switch also announces the ap-
propriate mode. (p. 12-15)
The output level of the voice synthesizer can be
adjusted in level set mode. (p. 12-6)
SPEECH
SPEECH
■
Voice synthesizer operation
EXIT/SET
F-7
SET
F-3
DISP
F-1
∫
F-2
√
S
Po
1 3 5 7 9
250W 200 100 150 50 0
+20 +40 +60dB
S
Po
1 3 5 7 9
250W 200 100 150 50 0 10
+20 +40 +60dB
SPEECH
