4-17
D D Editing RTTY memory
The contents of the RTTY memories can be set using
the memory edit menu. The memory can store and re-
transmit 8 RTTY message for often-used RTTY infor-
mation. Total capacity of the memory is 70 characters
per memory channel.
• Programming contents
q During RTTY mode operation, push [F-3•DECODE]
to select RTTY decode screen.
w Push [F-4•TX MEM] to select RTTY memory
screen, then push [F-6•EDIT] to select RTTY mem-
ory edit screen.
• RTTY memory contents of the Channel 1 (RT1) is se-
lected.
e Push [F-7•RT1..RT8] to several times to select the
desired RTTY memory channel to be edited.
r Push [F-5• Ω ≈ ] to select the edit item between
memory contents and memory name.
t Push [ABC] (MF6) , [abc] (MF6) , [123] (MF7) or [Sym-
bol] (MF7) to select the character group, then rotate
the main dial to select the character, or push the
keypad for number input.
• [abc] (MF6) appears when [ABC] (MF6) is pushed when
“ABC” character group is selected, and [Symbol] (MF7)
appears when [123] (MF7) is pushed when “123” char-
acter group is selected.
• Selectable characters (with the main dial);
✔
For your convenience
When a PC keyboard is connected to [USB] con-
nector on the front panel, the RTTY memory con-
tents can also be edited from the keyboard.
y Push [F-1• Ω ] or [F-2• ≈ ] to move the cursor back-
wards or forwards, respectively.
• Pushing [F-3•DEL] deletes a character and [F-4•SPACE]
inserts a space.
u Repeat steps t and y to input the desired charac-
ters.
i Push to set the contents and exit RTTY
memory edit screen.
EXIT/SET
RT1..RT8 EXIT/SET
F-7
/ / F-3
DEL
F-4
SPACE
123 Symbol ABC abc
F-1
Ω
F-2
≈
F-5
Ω ≈
4
RECEIVE AND TRANSMIT
• RTTY memory edit screen
Key selection Editable characters
A to Z (capital letters)
a to z (small letters)
(selectable for memory name only)
0 to 9 (numbers)
! # $ % & ¥ ? “ ‘ ` ^ + –
✱
/ . , : ; =
< > ( ) [ ] { } | _
~
@
(For the memory contents set-
ting, ! $ & ? “ ‘ – / . , : ; ( ) ↵ are
selectable.)
Symbol
123
abc
ABC CH Name Contents
RT1 MYCALLx2 ↵ DE ICOM ICOM K ↵
RT2 MYCALLx3 ↵ DE ICOM ICOM ICOM K ↵
RT3 QSLUR599 ↵ QSL UR 599–599 BK ↵
RT4 DE+UR599 ↵ QSL DE ICOM ICOM UR 599–599
BK ↵
RT5 73 GL SK ↵ 73 GL SK ↵
RT6 CQ CQ CQ ↵ CQ CQ CQ DE ICOM ICOM ICOM
K ↵
RT7 RIG&ANT ↵ MY TRANSCEIVER IS IC–7700 &
ANTENNA IS A 3–ELEMENT
TRIBAND YAGI.
↵
RT8 EQUIP. ↵ MY RTTY EQUIPMENT IS
INTERNAL FSK UNIT &
DEMODULATOR OF THE
IC–7700.
↵
• Pre-programmed contents
