14-4
D D Command table (continued)
14
CONTROL COMMAND
14 18 + Level data [CONTRAST] setting (0=max.
CCW to 255=max. CW)
19 + Level data [BRIGHT] setting
(0=max. CCW to 255=max. CW)
15 01 Read squelch condition
02 Read S-meter level
11 Read RF power meter
12 Read SWR meter
13 Read ALC meter
14 Read COMP meter
15 Read V D meter
16 Read I D meter
16 02 Send/read Preamp setting
(0=OFF; 1=preamp 1;
2=preamp 2)
12 Send/read AGC selection
(0=OFF; 1=Slow; 2=Mid; 3=Fast)
22 Send/read noise blanker setting
(0=OFF; 1=ON)
32 Send/read Audio peak filter set-
ting for CW mode
(APF type=SHARP: 0=OFF;
1=320 Hz; 2=160 Hz; 3=80 Hz,
APF type=SOFT: 0=OFF;
1=WIDE; 2=MID; 3=NAR)
40 Send/read noise reduction setting
(0=OFF; 1=ON)
41 Send/read auto notch setting
(0=OFF; 1=ON)
42 Send/read repeater tone setting
(0=OFF; 1=ON)
43 Send/read tone squelch setting
(0=OFF; 1=ON)
44 Send/read speech compressor
setting (0=OFF; 1=ON)
45 Send/read monitor setting
(0=OFF; 1=ON)
46 Send/read VOX function setting
(0=OFF; 1=ON)
47 Send/read Break-in function set-
ting (0=OFF; 1=semi break-in;
2=full break-in)
48 Send/read manual notch setting
(0=OFF; 1=ON)
4C Send/read VSC setting
(0=OFF; 1=ON)
4D Send/read Manual AGC setting
(0=OFF; 1=ON)
4E Send/read DIGI-SEL setting
(0=OFF; 1=ON)
4F Send/read twin peak filter setting
(0=OFF; 1=ON)
50 Send/read dial lock function set-
ting (0=OFF; 1=ON)
53 Send/read RX antenna connector
setting (0=OFF; 1=ON)
19 00 Read the transceiver ID
1A 00 Send/read memory contents (see
p. 14-9 for details)
01 Send/read band stacking register
contents (see p. 14-9 for details)
02 Send/read memory keyer con-
tents (see p. 14-9 for details)
1A 03 Send/read the selected filter width
(SSB, CW, PSK: 0=50 Hz to
40=3600 Hz; RTTY: 0=50 Hz to
31=2700 Hz; AM: 0=200 Hz to
49=10 kHz)
04 Send/read the selected AGC time
constant (0=OFF, 1=0.1/0.3 sec.
to 13=6.0/8.0 sec.)
050001 Send/read SSB RX HPF/LPF
(HPF: 0=Through, 1=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
050002 Send/read SSB RX Tone (Bass)
level (0 =–5 to 10=+5)
050003 Send/read SSB RX Tone (Treble)
level (0=–5 to 10=+5)
050004 Send/read AM RX HPF/LPF
(HPF: 0=Through, 1=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
050005 Send/read AM RX Tone (Bass)
level (0 =–5 to 10=+5)
050006 Send/read AM RX Tone (Treble)
level (0=–5 to 10=+5)
050007 Send/read FM RX HPF/LPF
(HPF: 0=Through, 1=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
050008 Send/read FM RX Tone (Bass)
level (0 =–5 to 10=+5)
050009 Send/read FM RX Tone (Treble)
level (0=–5 to 10=+5)
050010 Send/read CW RX HPF/LPF
(HPF: 0=Through, 1=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
050011 Send/read RTTY RX HPF/LPF
(HPF: 0=Through, 1=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
050012 Send/read PSK RX HPF/LPF
(HPF: 0=Through, 1=100 to
20=2000, LPF: 5=500 to
24=2400, 25=Through)
050013 Send/read SSB TX Tone (Bass)
level (0 =–5 to 10=+5)
050014 Send/read SSB TX Tone (Treble)
level (0=–5 to 10=+5)
050015 Send/read AM TX Tone (Bass)
level (0 =–5 to 10=+5)
050016 Send/read AM TX Tone (Treble)
level (0=–5 to 10=+5)
050017 Send/read FM TX Tone (Bass)
level (0 =–5 to 10=+5)
050018 Send/read FM TX Tone (Treble)
level (0=–5 to 10=+5)
050019 Send/read SSB TX bandwidth for
wide (see p. 14-10 for details)
050020 Send/read SSB TX bandwidth for
mid. (see p. 14-10 for details)
050021 Send/read SSB TX bandwidth for
narrow (see p. 14-10 for details)
050022 Send/read speech level
(0=0% to 255=100%)
Command Sub command Description Command Sub command Description
