1-9
$7
MEMO PAD-WRITE SWITCH (p. 8-7)
Programs the displayed readout frequency and op-
erating mode into a memo pad.
• The 5 most recent entries remain in memo pads.
• The memo pad capacity can be expanded from 5 to 10
in set mode. (p. 12-15)
$8 MEMO PAD-READ SWITCH (p. 8-7)
Each push calls up a frequency and operating mode
in a memo pad. The 5 (or 10) most recently pro-
grammed frequencies and operating modes can be
recalled, starting from the most recent.
• The memo pad capacity can be expanded from 5 to 10
in set mode. (p. 12-15)
$9 VFO/MEMORY SWITCH
➥
Switches the selected readout operating mode
between the VFO and memory when pushed.
(pgs. 3-3, 8-2)
➥ Transfers the memory contents to VFO when
pushed and held for 1 sec. (p. 8-4)
%0 VFO EQUALIZING SWITCH (p. 3-3)
Transfers the undisplayed VFO frequency to the
displayed VFO frequency when pushed and held for
1 sec.
%1
FILTER SWITCH (p. 5-13)
➥
Selects one of 3 IF filter settings.
➥ Enters the filter set screen when pushed and
held for 1 sec.
%2
AUDIO PEAK FILTER/TWIN PEAK FILTER
SWITCH
➥
Push to turn the audio peak filter ON and OFF
during CW mode operation. (p. 4-6)
• “ ” appears when audio peak filter is in use.
➥
Push to turn the twin peak filter ON and OFF dur-
ing RTTY mode operation. (p. 4-14)
• “ ” appears when twin peak filter is in use.
➥ During CW mode operation, push and hold for
1 sec. to select the APF passband width from
320, 160 and 80 Hz. (p. 4-6)
%3
MINI SPECTRUM SCOPE SWITCH
(p. 5-4)
➥
Turns the mini spectrum scope screen ON and
OFF when pushed.
• The mini spectrum scope screen can be displayed
with another screen, such as memory or set mode
screen, simultaneously.
➥
Turns the spectrum scope screen ON when
pushed and held for 1 sec.
%4
VOICE MEMORY RECORD SWITCH
(p. 7-3)
➥
Push to record the received signal for the preset
time period.
• After the preset time has passed, stops recording au-
tomatically.
➥ Push and hold for 1 sec. to record the received
signal until the recording is canceled.
• Push this switch momentarily to stop recording.
• The memory records the latest 30 sec. of audio.
%5
VOICE MEMORY PLAYBACK SWITCH
(p. 7-4)
➥ Plays back the previously recorded audio for the
preset time period when pushed.
➥
Plays back all of the previously recorded audio
when pushed and held for 1 sec.
%6
EXIT/SET SWITCH
➥
Push to exit, or return to the previous screen in-
dication during spectrum scope, memory, scan or
set mode screen display.
➥
Displays set mode menu screen when pushed
and held for 1 sec.
%7
MAIN DIAL
Changes the displayed frequency, selects set mode
setting, etc.
%8 LOCK SWITCH [LOCK] (p. 5-17)
Push to switch the dial lock function ON and OFF.
%9 SPEECH SWITCH (p. 3-11)
➥
Push to announce the S-meter indication and the
selected frequency.
➥
The selected operating mode is additionally an-
nounced when pushed and held for 1 sec.
^0 SPLIT SWITCH (p. 6-6)
➥ Turns the split function ON and OFF when
pushed.
➥
Turns the split function ON. When pushed and
held for 1 sec. in non-FM modes, transfers the
unselected VFO’s readout frequency to the se-
lected VFO’s readout and sets the unselected
VFO to transmit VFO.
(Quick split function)
• The offset frequency is shifted from the selected VFO
frequency in FM mode. (p. 12-13)
• The quick split function can be turned OFF using set
mode. (p. 12-12)
➥
Turns the split function ON and shifts the unse-
lected VFO frequency after inputting an offset.
SPLIT
SPEECH
EXIT/SET
PLAY
REC
M.SCOPE
TPF
APF
APF/TPF
FILTER
A=B
V/M
MP-R
MP-W
1
PANEL DESCRIPTION
