Basic Input Output System (BIOS) STL2 Server Board TPS
4-54
Code Error Message Failure Description
0B93: BMC SDR Repository empty. BMC device (chip) failed
0B94: IPMB signal lines do not respond. SMC(Satellite Management Controller) failed
(Available for use except for the access
function to SMC via IPMB)
0B95 BMC FRU device failure. SROM storing chassis information failed
(Available for use except for FRU command
and EMP function.)
0B96 BMC SDR Repository failure. BMC device (chip) failed
0B97 BMC SEL device failure.
0BB0: SMBIOS – SROM data read error SROM data read error
0BB1: SMBIOS – SROM data checksum bad Bad checksum of SROM data
0BD0: 1st SMBus device address not acknowledged. Some SMBus device (chip) failed
0BD1: 1st SMBus device Error detected.
0BD2: 1st SMBus timeout.
Expansion ROM not initialized. PCI Expansion ROM card not initialized
Invalid System Configuration Data System configuration data destroyed
System Configuration Data Read Error System configuration data read error
Resource Conflict PCI card resource is not mapped correctly.
System Configuration Data Write error System configuration data write error
Warning: IRQ not configured PCI interrupt is not configured correctly.
8503: Incorrect memory speed in location: XX, XX, … Non-PC133 DIMMs have been installed in slots
XX, XX, …
A beep code is a series of individual beeps on the PC speaker, each of equal length. The
following table describes the error conditions associated with each beep code and the
corresponding POST check point code as seen by a port 80h card. For example, if an error
occurs at checkpoint 22h, a beep code of 1-3-1-1 is generated. The beep codes 1-1-1-1, 1-5-
1-1, 1-5-2-1 and 1-5-3-1 are reserved for BMC usage.
Beeps Error Cause Recommended Action
1-2-2-3 ROM Checksum Error — Change system board
1-3-1-1 DRAM Refresh Test Error — Change memory DIMM's
1-3-1-3 Keyboard Controller Test Error — Change system board
1-3-3-1 Memory Not Detected No memory.
Can not write to memory
Verify DIMM installation.
Change memory DIMM's
Memory Capacity Check Error No memory.
Can not write to memory
Verify DIMM installation.
Change memory DIMM's
1-3-4-1 DRAM Address Test Error Memory address signal failure Change DIMM or M/B
1-3-4-3 DRAM Test low byte Error Memory data signal failure (low) Change DIMM or M/B
1-4-1-1 DRAM Test high byte Error Memory data signal failure (high) Change DIMM or M/B
1-4-3-3 All Memory Group Errors — —
2-1-2-3 BIOS ROM Copy-Write Test Error Error with Shadow RAM Change system board
2-2-3-1 Unexpected Interrupt Test Error Unexpected interrupt Change CPU or system board
2-3-1-3 All Memory Group Errors Memory address signal failure Change DIMM or M/B
