STL2 Server Board TPS Server Management
Revision 1.0 3-25
Sensor Number Sensor Type Monitoring Device
94h BIOS POST (Error) Code
95h Log Disable Log Area Reset / Cleared (bit 2)
ECC single bit Error Disable (bit 0)
96h System Event OEM System Event (Hard Reset) (bit 1) System
97h Critical Interrupt PCI SERR (bit 5)
PCI PERR (bit 4)
Front Panel NMI (Dump SW) (bit 0)
98h Button Reset Button (bit 2)
Sleep Button (bit 1)
Power Button (bit 0)
99h No Processor or Termination Board
9Ah Boot Init User requested PXE boot (bit 3)
Initiated by power up (bit 0)
9Bh Boot Error PXE Server not found (bit 2)
No bootable media (bit 0)
9Ch OS Boot
9Dh OS Stop
9Eh ACPI State Sleeping in S1 state (bit 8)
G3/Mechanical Off (bit 7)
S5 / G2 Soft Off (bit 5)
S4 (bit 4)
A0h BMC Watchdog BMC WDT Timeout
C0h Chassis Intrusion ID (Disable) Processor Area Intrusion (bit 4)
C1h Chassis Intrusion ID Drive Bay Intrusion (bit 1)
F3h SMI State SMI Stall State
The following table provides a list of System Event Log (SEL) events supported by the STL2
server board.
Sensor Type Sensor Type
Code Sensor-Specific
Offset Event Remarks
Reserved 00h – Reserved
Temperature 01h – Temperature An error occurred at thermal sensors
Voltage 02h – Voltage An error occurred at voltage sensors
01h Performance Lags In the single-end event mode, even if
SCSI is available for a different
mode event.
Fan 04h – Fan An error occurred at fan sensors.
Physical Security 05h 01h Drive Bay Intrusion Front cover has been opened or
closed
03h Processor area intrusion Side (Chassis) cover has been
opened or closed.
04h LAN Connection Lost
(System has been
unplugged from LAN) LAN cable has
been plugged
in or
unplugged.
