Basic Input Output System (BIOS)
STL2 Server Board TPS
4-36
4.2.2.5 Advanced Menu Selections
The following tables describe the menu options and associated submenus available on the
Advanced Menu. Please note that MPS 1.4 / 1.1 selection is no longer configurable. The BIOS
will always build MPS 1.4 tables.
Table 4-5. Advanced Menu Selections
Feature
Choices or Display
Only
Description
User Setting
Memory Reconfiguration
Refer to Memory Reconfiguration Submenu.
Peripheral Configuration
Refer to Peripheral Reconfiguration
Submenu.
PCI Device
Refer to PCI Device Submenu.
Option ROM
Refer to Option ROM Submenu. It
Disables/Enables the Option ROM BIOS on
the PCI Bus.
Numlock
Refer to Numlock Submenu.
Reset Configuration Data
No
Yes
Clears the Extended System Configuration
Data if selected.
Installed O/S
Other
PnP O/S
Selects the type of operating system that will
be used most.
Table 4-6. Memory Reconfiruation Submenu Selections
Feature
Choices or Display
Only
Description
User Setting
System Memory
XXX KB
(Display Only). Indicates the total capacity of the
basic memory.
Extended Memory
XXXXXX KB
(Display Only). Indicates the total capacity of the
extended memory.
DIMM #1 Status
Normal
1
(Display Only)
DIMM #2 Status
Normal
1
(Display Only)
DIMM #3 Status
Normal
1
(Display Only)
DIMM #4 Status
Normal
1
(Display Only)
Clear DIMM Errors
Press Enter
Clears the DIMM group error status information.
DIMM Error Pause
Enabled
Disabled
If enabled, the POST operation pauses if a DIMM
error occurs.
Note:
1. Possible Values: Normal, None, or Error (DIMM Row Error).
