display product directly to you. Using the prepaid shipping labels
provided, return your failed display to HP in the same packaging as the
replacement. Certain restrictions and exclusions apply. For details see
your product warranty or contact HP Customer Support.
HP LP3065 30-inch
Widescreen LCD
Monitor Panel Type 30.0-inch Wide Format Active Matrix TFT
(thin film transistor)
Viewable Image Area
(diagonal) 29.77 in (75.623 cm)
Screen Opening
(W x H) 25.3 x 15.8 in (64.3 x 40.3 cm)
Viewing Angle (typical)*Up to 178° H/ 178° V (10:1 minimum contrast
ratio)
Brightness (typical)* 300 nits (cd/m 2 )
Contrast Ratio (typical)* 1000:1
Response Rate
(typical)* 12 ms (8 ms average gray to gray)
Pixel Pitch 0.250 mm
Color Depth Support 16.7 million colors
Backlight Lamp Life
(to half brightness) 40K hours
Color Gamut 92% of NTSC
On Screen Display
(OSD) Controls Buttons or Switches Input select, brightness up, brightness down,
power
User Controls Brightness, input selection
Signal Interface/
Performance Horizontal Frequency 100 KHz
Vertical Frequency 60 Hz
Native Resolution 2560 x 1600 @ 60 Hz
(native aspect ratio of 16:10)
Pixel Clock Speed 275 MHz
Anti-Glare Yes
Anti-Static Yes
Default Color
Temperature 6500 K
Video/Other Inputs Plug and Play Yes
Self Powered USB 2.0
Hub One upstream, four downstream ports
(located on side of monitor, cable included)
Input Signal Three dual-link DVI-D inputs
(Windows PC and graphics card that supports
DVI ports with dual-link digital bandwidth and
VESA DDC standard for plug-and-play setup
requires a DVI-D dual-link graphic card that
supports WQXGA
(2560 x 1600) resolution.)
Video Cable Two dual-link DVI cables
Video Cable Length 5.9 ft (1.8 m)
Power Input Power Auto-Ranging, 100 to 240 VAC; internal
power supply, 50 Hz/60 Hz
Typical Power
Consumption 118 watts
QuickSpecs
HP xw8600 Workstation
Technical Specifications - Monitors
DA - 12849 Worldwide QuickSpecs — Version 10 — 6.1.2008 Page 68
