HP xw8600 - Manual (Page 31)

High Definition
Integrated Realtek
ALC262 Audio Type Integrated
High Definition Codec Yes
SPDIF No
External audio jacks One front stereo analog microphone-in
One front stereo headphone-out
One rear line-in
One rear line-out
One rear stereo analog microphone-in
Internal audio
connectors AUX-IN line-level analog input
Retasking NOTE: All external audio ports are retaskable as Line-In, Line-Out,
Microphone-In, or Headphone-Out
Sampling 44.1kHz/48 kHz/96kHz/192kHz (output only)
Wavetable syntheses
(software) Yes - Uses OS soft wavetable
Digital audio Yes
Analog audio Yes
Number of channels on
Line-Out
(mono/stereo) Two independent stereo outputs (Left & Right channels)
Internal audio speaker
power rating 1.5 W
Internal speaker Yes
Microphone features Stereo Microphone supporting:
Acoustic echo cancellation
Noise suppression
Beam forming
HP Thin USB Powered
Speakers
(KK912AA) On/Off/Volume
Controls Right side of right speaker
Power LED Front of right speaker (green)
Frequency response FO to 20kHz
Watts 2/3 watt (normal/maximum)
Dimensions (H x W x D) Speakers: 5.72 x 3.74 x 0.96 in (14.52 x 9.50 x 2.45 cm) per speaker
Net weight 0.68 lbs (0.31kg)
Environmental
(all conditions
non-condensing) Temperature (operating) 14° to 104° F (-10° to 40° C)
Relative Humidity
(operating) 40% to 90%
Speaker cable length Input cord: 5.91 ft (1800mm±35mm)
L-channel cord: 3.28 ft (1000mm±35mm)
USB cord: 5.91 ft (1800mm±35mm)
Color HP Carbonite
Option kit contents One pair of HP Thin USB Powered Speakers with attached audio
signal and USB power cables for connecting to your PC
HP Warranty documentation
QuickSpecs
HP xw8600 Workstation
Technical Specifications - Audio
DA - 12849 Worldwide QuickSpecs — Version 10 — 6.1.2008 Page 31
