(LSI 1068X)* Support one RAID array with 2-5(6) drives
Supports two RAID arrays with 2 drives each
RAID 0 Configuration - Striped Array
RAID 1 Configuration - Mirrored Array
RAID 10 Configuration - Stripe of Mirrors
External RAID arrays possible
NOTE: Specific user-configured hardware SAS RAID configurations are supported on this Linux
system. Please visit: http://www.hp.com/support/linux_hardware_matrix for details.
SAS/SATA Connectors 6 SATA only connectors
4 SAS connectors, 2 of these SAS connectors (color coded red) can be used for External SATA
(eSATA) with the appropriate eSATA After Market Option kit
IEEE 1394 Connectors 1 IEEE 1394b rear connector, 1 IEEE 1394a header for front connector (Not supported in Linux)
USB 2.0 Connectors 8 total: 5 rear, 2 on header for front connectors, 1 internal
Power Supply Headers 2x12 connector, 2x4 CPU connector, 2x3 memory connector
Power Switch, Power
LED & Hard Drive LED
Header Power switch, power LED, and hard drive LED cables connect to the Control Panel connector.
There is also a 2 pin header to connect a SCSI LED cable to the motherboard.
Password Clear Header Yes
Cooling
Power Supply Fan
92 mm x 32 mm
Memory Fan 92 mm x 25 mm (for systems without memory risers)
Processor Fan-Heatsink 80 mm x 15 mm (single or dual)
Chassis Fan (rear) One 120 mm x 25 mm
Optional Front PCI fan 80 mm x 25 mm - not required for most workstation compute environments
Power Supply
Power Supply
800W Custom PSU
(Wide Ranging, Active PFC)
1050W Custom PSU –
(Wide Ranging, Active PFC)
Operating Voltage
Range 90 – 269 VAC 90 – 269 VAC
Rated Voltage Range 100 – 240 VAC 118 VAC 100 – 240 VAC 118 VAC
Rated Line Frequency 50/60Hz 400Hz 50/60 Hz 400Hz
Operating Line
Frequency Range 47 – 66 Hz 393 – 407 Hz 47 – 66 Hz 393 – 407 Hz
Rated Input Current 10.0A @ 100-127 VAC
6A @ 200-240 VAC
9.5A @ 118 VACC 13.2A @ 100-127 VAC
6.6A @ 200-240 VAC
12.0A @ 118 VAC
Heat Dissipation
(Configuration and
software dependent) Typical 1530 btu/hr (386 kg-cal/hr)
Maximum 2027 btu/hr (511 kg-cal/hr)
Typical 3136 btu/hr (791 kg-cal/hr)
Maximum 4480 btu/hr (1129kg-cal/hr)
Power Supply Fan 92x32 mm variable speed 92x32 mm variable speed
Energy Star 4.0
Compliant Yes Yes
80 PLUS® Compliant Yes Yes
FEMP Standby Power
Compliant @115V
(<2W in S5 – Power Off,
with Wake on LAN
disabled) Yes No
QuickSpecs
HP xw8600 Workstation
Technical Specifications
DA - 12849 Worldwide QuickSpecs — Version 10 — 6.1.2008 Page 20
