HP xw8600 - Manual (Page 62)

Brightness (typical* Up to 300 nits (cd/m 2 )
Contrast Ratio (typical)* Up to 800:1
Response Rate
(typical)* 8 ms (gray to gray), 16 ms (rise + fall)
Pixel Pitch 0.255 mm
Color Depth Support 16.7 million colors
Backlight Lamp Life
(to half brightness) 45K hours
On Screen Display
(OSD) Controls Buttons or Switches Input select, auto adjust/OSD up, OSD down,
OSD menu select, power
Languages English, French, German, Spanish, Italian,
Dutch, and Japanese
User Controls Brightness, contrast, positioning, color
temperature, individual color control, serial
number display, full screen resolutions, clock,
clock phase, input selection, image control
(including scaling), and factory reset
Signal Interface/
Performance Horizontal Frequency 30 to 94 kHz (VGA input); 30 to 92 KHz (DVI
input for modes with pixel clock less than 157
MHz)
Vertical Frequency 48 to 85 Hz (VGA input); 30 to 92 KHz (DVI
input for modes with pixel clock less than 157
MHz)
Native Resolution 1600 x 1200 @ 60 Hz (recommended)
Preset VESA Graphic
Modes (non-interlaced) 1600 x 1200 @ 60 Hz, 75 Hz (VGA input)
1280 x 1024 @ 60 Hz, 75 Hz, 85 Hz
1280 x 960 @ 60 Hz
1152 x 900 @ 66 Hz
1024 x 768 @ 60 Hz, 75 Hz, 85 Hz
800 x 600 @ 60 Hz, 85 Hz
640 x 480 @ 60 Hz, 75 Hz, 85 Hz
Text Mode 720 x 400 @ 70 Hz
Mac Mode 1152 x 870 @ 75 Hz and 832 x 624 @ 75 Hz
Sun Mode 1152 x 900 @ 66 Hz
Maximum Pixel Clock
Speed 202 MHz (VGA input); 162 MHz (DVI input)
User Programmable
Modes Yes, 10
Anti-Glare Yes
Anti-Static Yes
Default Color
Temperature 6500 K
Video Input Plug and Play Yes
Input Signal Four connectors, including one 15-pin mini D-
sub VGA, one DVI-I (VGA analog and digital
input), one composite video, and one s-video
Self Powered USB 2.0
Hub One upstream, four downstream ports (cable
included)
Input Signal Two DVI-I connectors (dual VGA analog or
dual digital input possible)
QuickSpecs
HP xw8600 Workstation
Technical Specifications - Monitors
DA - 12849 Worldwide QuickSpecs — Version 10 — 6.1.2008 Page 62
