HP L1965 19-inch LCD
Monitor Panel Type Active matrix, thin film transistor (TFT)
Viewable Image Area
(diagonal) 19 inches; 48.25 cm maximum viewable
Screen Opening (WxH) 14.9 x 12.0 inches; 38.0 x 30.5 cm
Viewing Angle (typical) 178 degrees horizontal/178 degrees vertical
(10:1 minimum contrast ratio)
Brightness (typical) 300 nits (cd/m 2 )
Contrast Ratio (typical) 1000:1 (typical)
Response Rate (typical) 6 ms (typical gray to gray)**
Pixel Pitch 0.294 mm
Color Depth Support 16.7 million colors
Backlight Lamp Life
(to half brightness) 50K hours
* All performance specifications represent the typical specifications
provided by HP's component manufacturers; actual performance may
vary either higher or lower.
** 20 ms rise and fall
Video/Other Inputs Plug and Play Yes (supports VESA DDC2B and DDC/CI;
PC2001 compliant)
Self Powered USB 2.0
Hub One upstream, four downstream ports (cable
included)
Input Signal Two DVI-I connectors (VGA analog or digital)
Input Impedance 75 ohms ± 2%
Sync Input Separate sync (HSYNC/VSYNC); composite
sync, Sync on Green (activated through on-
screen display)
Video Cable One DVI-D to DVI-D, and 1 DVI-I to VGA
cables
Video Cable Length 71 in (1.8 m)
Signal Interface/
Performance Horizontal Frequency 24 to 83 kHz
Vertical Frequency 48 to 76 Hz
Native Resolution 1280 x 1024 @ 75 Hz analog
1280 x 1024 @ 60 Hz digital
Maximum Resolution
(Analog) 1280 x 1024 @ 75 Hz analog
Maximum Resolution
(Digital) 1280 x 1024 @ 75 Hz digital
Preset VESA Graphic
Modes (non-interlaced) 640 x 480 @ 60 Hz, 72 Hz, 75 Hz
720 x 400 @ 70 Hz
800 x 600 @ 60 Hz, 72 Hz, 75 Hz
1024 x 768 @ 60 Hz, 70 Hz, 75 Hz
1280 x 1024 @ 60 Hz, 75 Hz
Preset MAC Mode 832 x 624 @ 75 Hz
1152 x 870 @75 Hz
Preset VGA Mode 640 x 480 @ 60 Hz, 72 Hz
Preset SUN Mode 1152 x 900 @ 76 Hz
Fail Safe Mode Yes (limits out of range signal messages)
Maximum Pixel Clock
Speed 140 MHz
QuickSpecs
HP xw8600 Workstation
Technical Specifications - Monitors
DA - 12849 Worldwide QuickSpecs — Version 10 — 6.1.2008 Page 56
