HP xw8600 - Manual (Page 58)

Tilt Range -4 degrees to +30 degrees
Swivel Range ± 45 degrees horizontal swivel
Height Adjustable Yes (4 in/100mm adjustment range)
Pivot Rotation Yes, 90 degrees
Base Ships attached and is removable
Environmental Temperature –
Operating 41° to 95° F (5° to 35° C)
Temperature – Non-
operating -4° to 140° F (-20° to 60° C)
Humidity – Operating 20% to 80%
Humidity – Non-
operating 5% to 95%
Altitude – Operating 0 to 12,000 ft (0 to 3,658 m)
Altitude – Non-
operating 0 to 40,000 feet; 0 to 12,192 m
Environmental Data Eco-Label
Certifications and
Declarations This product has received or is in the process
of being certified to the following approvals
and may be labeled with one or more of these
marks:
US Energy Star
CECP
Energy
Consumption
(in accordance
with US Energy
Star test method)
AC Input
Voltage at 100
VAC +/- 5 VAC,
50 Hz +/- 3 Hz
AC Input
Voltage at 115
VAC +/- 5 VAC,
60 Hz +/- 3 Hz
AC Input
Voltage at 230
VAC +/- 5 VAC,
50 Hz +/- 3 Hz
Normal
Operation
35.7 watts 35.6 watts 35.1 watts
Sleep 1.08 watts 1.14watts 1.23 watts
Off 0.93 watts 0.94 watts 0.92 watts
Heat
Dissipation*
100 VAC, 50 Hz 115 VAC, 60 Hz 230 VAC, 50 Hz
Normal
Operation
121.7 BTU/hr 121.4 BTU/hr 119.7 BTU/hr
Sleep 3.68 BTU/hr 3.89 BTU/hr 4.19 BTU/hr
Off 3.17 BTU/hr 3.21 BTU/hr 3.14 BTU/hr
* Heat dissipation is calculated based on the measured watts,
assuming the service level is attained for one hour.
Longevity and
Upgrading Upgradeability features contained in the
product include:
One upstream and four downstream USB
ports
Ergonomics The monitor meets the ergonomic
requirement of EN-ISO 13406-2 for flat panel
displays.
Additional Information This product is in compliance with the
Restrictions of Hazardous Substances
(RoHS) Directive, 2002/95/EC.
This HP product is designed to comply with
the Waste Electrical and Electronic
Equipment (WEEE) Directive, 2002/96/EC.
QuickSpecs
HP xw8600 Workstation
Technical Specifications - Monitors
DA - 12849 Worldwide QuickSpecs — Version 10 — 6.1.2008 Page 58
