Environmental Operating temperature 32° to 131° F (0° to 55° C)
Operating humidity 85% at 131° F (55° C)
Dimensions 4.4 x 2.2 x 0.08 inches; 11.2 x 5.5 x 0.2 cm
Operating system
driver support Microsoft Windows Vista Business 32 and 64, Microsoft Windows 2000
and XP, Red Hat Linux 7.2, 7.3 and Red Hat Enterprise Linux 3
Management
capabilities WOL, PXE , Remote cable management
Alerting ASF 2.0
Kit contents Broadcom 5751, CD, Broadcom 5751 Netxtreme Gigabit PCIe NIC,
drivers, quick install guide, product warranty statement
LSI MegaRAID® SAS
8888ELP Host Bus
Adapter (HBA) PCI Bus PCI-Express x8 lanes
PCI Modes Bus Master DMA
PCI data burst transfer
rate Up to 3Gb/s per port
SAS Bandwidths Up to 1.5 GB/s
PCI Voltage/Card Type +3.3V Add-in Card
PCI Form Factor 7.71 x 2.54 in (19.59 x 6.44cm) (Low-profile, extended half-length)
PCI Power 7.5 Watts
Bracket Low-profile, extended half-length
Certification Level PCI-Express 1.0a
IO Bus Eight 3Gb/s SAS/SATA ports
SAS Processor LSI SAS1078
Internal Connectors Two SAS SFF8088 x4
External Connectors Two SAS SFF8087 x4
Max. Number of
Physical Devices 32
LED Indicators Connector LEDs indicate whether the internal or external connector is
active for ports 0-3 and 4-7
RAID Levels RAID 0, 1, and 5
RAID spans 10 and 50
Environments Operating Storage
Temperature 32° to 122° F (0° to 50° C) -49° to +221° F (-45° to +105° C)
Relative Humidity 5% to 90% non-condensing 5% to 90% non-condensing
Compliances EN55022, EN50082, EN60950; FCC Class A, Class B; Ul1950; UL;
CSA C22.2; VCCI; AS3548; BSMI; MIC
Operating system
support Microsoft® Windows® XP Professional, XP Professional 64-bit
Genuine Windows Vista® Business 32-bit
Genuine Windows Vista® Business 64-bit
Red Hat Linux 7.2, 7.3, WS3 and WS4
QuickSpecs
HP xw8600 Workstation
Technical Specifications - Controllers
DA - 12849 Worldwide QuickSpecs — Version 10 — 6.1.2008 Page 35
