14 Setup
Control Options
•
Input Select, Exit, Vol ( + )/( – ), CH ( + )/( – ), and Menu on the main unit have the same functions
as the same buttons on the remote control. This manual describes the features through the remote
control keys.
Power Management System (For PC Mode Only)
The LCD TV has a power management function that automatically reduces power consumption in three
power-saving modes when not in use.
State LED Video Power
On Blue TV on, video input active 185W (typical)
Standby Red TV on, but video not
present < 5W
Off Off TV is off < 5W
Timing Mode
Mode Resolution Horizontal Frequency (KHz) Vertical (Hz)
1 VGA 720 x 400 31.47 kHz 70 Hz
2 VGA 640 x 480 31.47 kHz 70 Hz
3 VESA 640 x 480 31.47 kHz 60 Hz
4 VESA 640 x 480 37.50 kHz 75 Hz
5 VESA 800 x 600 37.88 kHz 60 Hz
6 VESA 800 x 600 46.88 kHz 75 Hz
7 VESA 1024 x 768 48.36 kHz 60 Hz
8 VESA 1024 x 768 60.02 kHz 75 Hz
9 VESA 1280 x 768 47.78 kHz 60 Hz
10 VESA 1280 x 768 68.28 kHz 75Hz
