Henny Penny OFE/OFG-322 - Manual (Page 29)

Model OFE/OFG-321,322,323,324
2-24. AUTOLIFT PC BOARD
REPLACEMENT
(if applicable) (Continued)
4. Using a Phillips-head screwdriver, remove the 2 screws
securing the autolift PC board bracket to the frame and remove
bracket from unit. (The right screw needs removed to
disconnect the ground wire, but the left screw can be loosened
and the bracket slid forward to be removed through the slots.)
5. Using 5/16” nut-driver or wrench, remove the 4 nuts securing
Figure 2-77 the autolift PC board to the bracket and remove PC board from
bracket.
6. Install new panel in reverse order.
606
2-29
