Henny Penny OFE/OFG-322 - Manual (Page 26)

Model OFE/OFG-321,322,323,324
2-22. AUTOLIFT
ACTUATOR (MOTOR)
REPLACEMENT
(if applicable) (Continued)
5. Disconnect actuator connector and cut the wires from the other
half of the connector, as shown at left. The new actuator wires
do not have a connector on them and must be connected
directly to the wires on the unit.
6. Using a 3/8 socket, remove the 3 nuts securing the bottom of
the actuator bracket.
7. Remove trim strip from front of shroud.
8. Using a 15T torx driver, remove the 4 torx screws from the pair
of actuators.
2-26 606
CUT WIRES
HERE
