69
LT0B-15A1
LCD Panel Size 15-inch TFT
Aspect Ratio 4:3
Best Resolution 1024 (horizontal) x 768 (vertical)
Maximum Display Area 304.1 mm (H) x 228.1 mm (W)
TV System NTSC
Video System
VGA input (15 pin D-SUB), S-Video Input and Compos-
ite Video Input (through the 4-IN-1 cable)
Audio System
Line in
10-pin mini-DIN (Audio Input through the 4-IN-1 Cable)
3.5 mm ø headphone jack x 1 (Audio Output)
Built-in Speakers 3W + 3W
Power Supply 100-240V, 50/60 Hz, 12V DC
Power Consumption 60 W Max.
Power Consumption (Standby) 7.7 W Max. (at 110Vac/60Hz)
Optional Accessories External Speakers
Weight (including base) 5.4 kg
Dimensions (including base) 468 mm (H) x 406 mm (W) x 156 mm (D)
14
Specifications
PC Mode Support Timing
