Connecting the Power Adapter
1
Connect the power cord to the power adapter as illustrated.
2
Plug the power adapter connector into the DC-IN input jack on the
rear panel of the TV.
3
Insert the three-pronged plug at the other end of the power cord into
a power outlet.
DC-IN input jack
DC-IN
VGA
LINE-OUT
LINE-IN
AV2
VIDEO
R-AUDIO-L
ANT
DC-IN
VGA
ANT
LINE-OUT
LINE-IN
AV2
VIDEO
R-AUDIO-L
Power cord
Power adapter
DC-IN
Power outlet
Three-pronged
plug
AC
