Page 23
22
Connecting to a Video Camera
The instructions presented here are a general guide to connecting the TV to
a camcorder or other type of digital camera. Actual connections may vary
according to the make and model of the device. Refer to the user’s manual
included with the camcorder or camera for more detailed instructions
.
Note
The cables are color-coded (black, red, white, yellow). Connect each color-
coded cable to the appropriate connector on your device.
DC-IN
VGA
LINE-OUT
LINE-IN
AV2
VIDEO
R-AUDIO-L
ANT
DC-IN
VGA
ANT
LINE-OUT
LINE-IN
AV2
VIDEO
R-AUDIO-L
WB
S
B
R
W
Y
4-IN-1 cable
S-Video
connector
AV connectors
4-IN-1 jack
