38 HP Pavilion home PC
Filename: ma2usqs.doc Title: HP-Print2k.dot
Template: HP-Print2K.dot Author: jiml Last Saved By: WASSER, Inc.
Revision #: 85 Page: 38 of 114 Printed: 04/12/02 08:01 AM
3 With the computer turned on, check the LEDs
(light-emitting diodes) on the network adapter.
The LEDs on each type of network adapter are
described below. (Refer to the illustration that
matches your system.)
LEDs
3 10 LNK — Lit green when connected to a
10BaseT port
3 100 LNK — Lit green when connected to
a 100BaseT port
3 ACT — Lit during network data transfer
activity
LEDs
3 100 — Lit green when connected to a
100BaseT port
3 LINK — Lit green with valid network
connection
LEDs
3 LINK — Lit green with valid network
connection
3 ACTIVITY — Lit yellow during network
data transfer activity
