36 HP Pavilion home PC
Filename: ma2usqs.doc Title: HP-Print2k.dot
Template: HP-Print2K.dot Author: jiml Last Saved By: WASSER, Inc.
Revision #: 85 Page: 36 of 114 Printed: 04/12/02 08:01 AM
3 On modems with a Telephone Line switch,
make sure the switch is in position 1.
Modem cable
Telephone
(optional)
1 2
Telephone cable
(optional)
Telephone
(optional)
Wall jack
Line
Back of PC
You can also connect a telephone to the
other connector on the modem (optional). By
connecting a telephone to the modem, you can
make regular (voice) telephone calls when you
are not using the modem — even if the computer
is turned off.
Setting Up the
Network Interface Adapter
The network interface adapter (also called a
network interface card, or
NIC) provides a
high-performance connection to an Ethernet
(10BaseT) or Fast Ethernet (100BaseT) network.
After this adapter is connected to a LAN (local
area network), you will be able to get a high-
speed connection to the Internet through the
LAN. For information about high-speed
providers, click the easy Internet sign-up
icon found on the desktop or in the Start menu
under All Programs.
