Internet
To identify the modem connector, look at the
back panel of the computer. The modem looks
similar to one of the following illustrations.
Note: Your computer may have only one
modem/telephone connection.
Modem connector
Or
Or
Telephone Line switch
Modem connector
1 2
To connect the cable between the modem and
the telephone line:
1 Plug one end of a modem cable into the Line
connector on the back of the computer. This
connector is labeled with either
Line or a jack
symbol.
2 Plug the other end of the cable into the
telephone line jack on the wall.
