Havis-Shields K9/Prisoner Transportation System KK-K9-F14-K-PT User Manual
Page 6
KK-K9-F14-K-PT_INST_11-08
6
View of assembly at this time
Place front partition filler panel
into vehicle as shown above
Position front partition as
shown and attach to K9
housing assembly
Remove “B” pillar upper trim
panel. Remove seat belt bolt
Remove bolt located behind
plastic trim
Remove grab handle
Remove trim panel to access
bolts for grab handle.
Position ¼” lexan shield
Using holes in partition mark and
drill shield Attach using ¼” x ¾”
carriage bolt and serrated nut
